(APPENDIX II) CONTROL UNIT SCREENS | PAGE 38
3. Measurements of genset voltage (V), genset current (A), fuel level (NC), engine
speed (RPM) and genset power (P).
GENERATOR: 5 0 . 0 H z
V 1 N 2 3 0 V I 1 0 A
N C 7 5 % R P M 1 5 0 0
P 0 k W
11.1.3. ENGINE STATUS SCREEN
1. Display of measurements for: engine speed RPM, H operating hours, NC fuel
level, DI battery charging alternator voltage, TM engine temperature, VB battery
voltage, PA oil pressure (integrated mode only - parameter 30, Regulations table,
value 0).
ENGINE: 1 5 0 0 R P M 1 0 0 H
N C 7 5 %
D I 1 4 V T M 7 0 º C
V B 2 4 V P A 6 . 7 B A R
NOTE
To display the engine temperature and oil pressure, the engine must be provided
with appropriate sensors.
In the event the engine readings are conducted through the extension CCJ1939,
the word ENGINE is replaced by the word J1939. Activation of the electronic
engine control is indicated by the ashing word J1939.
the phase currents and frequency. These voltage measurements are made by the
power module of the transfer switch controller (PHR7).
NETWORK: 5 0 . 0 H z
V 1 2 2 3 0 V V 1 N 4 0 0 V A
V 2 3 2 3 0 V V 2 N 4 0 0 V A
V 3 1 2 3 0 V V 3 N 4 0 0 V A
3. Switching control unit status.
SWITCHING: 0 . 0 H z
MANUAL
NETWORK: Undetected
K G - K R
ü
C K G - C K R
ü
11.1.2. GENERATOR MEASUREMENT SCREENS
1. Measurements of voltage between the various phases and neutral, the phase
currents and frequency. These voltage measurements are made by the power
module of the transfer switch controller (PHG7).
GENERATOR: 5 0 . 0 H z
V 1 N 2 3 0 V I 1 0 A
V 2 N 2 3 0 V I 2 0 A
V 3 N 2 3 0 V I 3 0 A
2. Measurements of voltage between phases, the currents per phase and
frequency. These voltage measurements are made by the power module of the
transfer switch controller (PHG7).
GENERATOR: 5 0 . 0 H z
V 1 2 4 0 0 V I 1 0 A
V 2 3 4 0 0 V I 2 0 A
V 3 1 4 0 0 V I 3 0 A
