Hioki 3286-20 - Specifications of Single-Phase Power Measurement 1Φ P Meter

41
―――――――――――――――――――――――――――
Chapter 3 Specifications
――――――――――――――――――――――――
Measurement
condition
Single phase, 50/60 Hz
Measurement range
Effective measurement current range:
1 A to 1000 A
Effective measurement voltage range:
80 V to 600 V
Out of range
If either the current (line current) range
or voltage (line voltage) range is out of
range, power measurement will also be
out of range.
Active power
measurement
Current
Volta
g
e
Current Range
20.00 A 200.0 A 1000 A
Voltage
Range
150.0 V 3.000
kW
30.00
kW
150.0
kW
300.0 V 6.000
kW
60.00
kW
300.0
kW
600 V 12.00
kW
120.0
kW
600.0
kW
Measurement
accuracy
2.3%rdg. 5dgt. (cosφ=1)
Apparent power S, reactive power measurement Q,
power factor COSφ
Method of
measurement
Measurement
accuracy
Measurement range
Obtained by calculation from active
power, current, and voltage
measurements.
1dgt.withrespecttocalculationfrom
each measured value.
[W] in the above table is replaced by
[VA] or [var].
3.1.3 Specifications of Single-phase Power
Measurement 1
φ
PMeter
