Hioki CM4371 - Current Measurement; Frequency Detection Range of AC Current; DC Current Polarity Detection Function

15
Current Measurement
Current Measurement
DC current polarity detection function (p. 34)
If the measured value is negative, the buzzer will
sound, and the display will turn red (threshold: -10 A).
e.g.: 3P4W (3-phase, 4-wire) circuit
breaker (AC current measurement)
4
HzAUTO
(AUTO AC/DC)
(AC+DC A)
(DC A)
(AC A)
3
Clamp the wire.
2
Press for 1 sec.
→Perform zero adjustment
1
Current
direction
Frequency detection range of AC current
CM4371, CM4372:
20.00 A range 4.00 A or more
600.0 A range 20.0 A or more
CM4373, CM4374:
600.0 A range 40.0 A or more
2000 A range 200 A or more
