Simultaneous display of DC current/voltage peak values
Simultaneous display of DC current/voltage peak values
Red Black
1
Press for 1 sec.
→PEAK display ON
2
Press for 1 sec.
→Cancel
4
(p. 28)
PEAK MIN
PEAK MAX
PEAK MIN
PEAK MAX
DC current
DC voltage
3
Engine starts
(PEAK occurrence)
Voltage: 60.00 V range (xed)
Current: 600.0 A range (xed) (CM4371, CM4372)
Trigger level: ±60 A
Current: 2000 A range (xed) (CM4373, CM4374)
Trigger level: ±200 A
