49
Accuracy Table
AC+DC current (PEAK MAX/PEAK MIN)
Range
(Accuracy
guarantee range)
Resolution
Accuracy guarantee
frequency range
Measurement accuracy
20.00 A (±1.0 A to ±150.0 A) 0.1 A 10 Hz≤f<45 Hz ±1.8% rdg.±0.7 A
DC, 45 Hz≤f≤66 Hz ±1.3% rdg.±0.7 A
66 Hz<f≤1 kHz ±2.0% rdg.±0.7 A
600.0 A (±10 A to ±1500 A) 1 A 10 Hz≤f<45 Hz ±1.8% rdg.±7 A
DC, 45 Hz≤f≤66 Hz ±1.3% rdg.±7 A
66 Hz<f≤1 kHz ±2.0% rdg.±7 A
4
Rush current (INRUSH) 600.0 A (CM4371, CM4372)
Conditions of guaranteed accuracy: After zero adjustment has been performed
INRUSH trigger level: For 600.0 A range, detection of current of +10 A or more or -10 A or less
Coupling type: DC coupling
Crest factor: For the 600.0 A range (500.0 A or less), 3
For the 600.0 A range (greater than 500.0 A and less than or equal to
600.0 A), 2.5
Peak detection time width: 1 ms or more
