Name: Hioki PW3198
Brand: Hioki
Rating: 4 (1 reviews)

To Next Page

To Previous Page

PRESETS function

U Events : Record and monitor voltage elements and frequency, plus detect events

Standard Power Quality : Record and monitor voltage and current elements, frequency, and harmonics, plus detect events

Inrush Current : Measure inrush current (basic voltage measurement required)

Recording : Record only trend data, no event detection

EN50160 : Measure according to EN50160 standards

Real-Time Clock function Auto-calendar, leap-year correcting 24-hour clock

Display Language English, Simplied Chinese, Japanese

Real-time clock accuracy ±0.3 s per day (with instrument on, 23°C±5°C (73°F±9°F)

Power supply AC ADAPTER Z1002 (12 VDC, Rated power supply 100VAC to 240VAC, 1.7Amax, 50/60Hz)

BATTERY PACK Z1003 (Ni-MH 7.2VDC 4500 mAh)

Maximum rated power 15VA (when not charging, except AC adapter), 35VA (when charging, except AC adapter)

Continuous battery operation time

Approx. 180 min. [@23°C (@73.4°F), when using BATTERY PACK Z1003]

Recharge function

BATTERY PACK Z1003 charges regardless of whether the instrument is on or off; charge time: max. 5 hr. 30 min. @23°C (@73.4°F)

Power outage processing

In the event of a power outage during recording, instrument resumes recording once the power is back on (integral power starts from 0).

Power supply quality measure-

ment method

IEC61000-4-30 Ed.2 :2008, IEEE1159

EN50160 (using Model PQA-HiVIEW PRO 9624-50)

Dimensions Approx. 300 W× 211 H × 68 D mm (11.81" W × 8.31" H × 2.68" D) (excluding protrusions)

Mass Approx. 2.6 kg (91.7 oz.) (including battery pack)

Accessories

Instruction manual, Measurement guide, VOLTAGE CORD L1000 (8 cords, approx. 3 m each: 1 each red, yellow, blue, and gray plus 4 black; 8 alligator

clips: 1 each red, yellow, blue, and gray plus 4 black), Spiral Tube, Input Cable Labels (for identifying channel of voltage cords and clamp-on sensors), AC

ADAPTER Z1002, Strap, USB cable (1 m length), BATTERY PACK Z1003, SD MEMORY CARD (2GB) Z4001

Display specications

Display 6.5-inch TFT color LCD (640 × 480 dots)

External Interface Specications

SD memory card Interface Saving of binary data, Saving and Loading setting les, Saving and Loading screen copies

Slot : SD standard compliant

Compatible card : SD memory card/ SDHC memory card (Use only HIOKI-approved SD memory cards)

Supported memory capacity

: SD memory card: Up to 2GB, SDHC memory card: Up to 32GB

Media full processing : Saving of data to SD memory card is stopped

RS-232C Interface Measurement and control using GPS-synchronized time (connecting GPS BOX)

Connector : D-sub9pin

Connection destination : GPS box (cannot be connected to computer)

LAN Interface 1. HTTP server function (compatible software: Internet Explorer Ver.6 or later, Remote operation application function,

measurement start and stop control functions, system conguration function, event list function (capable of displaying event

waveforms, event vectors, and event harmonic bar graphs)

2. Downloading of data from the SD memory card using the 9624-50 PQA-HiView Pro

Connector : RJ-45

Transmission method : 10BASE-T,100BASE-TX

USB2.0 Interface 1. Recognizes the SD memory card as a removable disk when connected to a computer.

The instrument cannot be connected during recording (including standby operation) or analysis.

2. Download data from the SD memory card using the 9624-50 PQA-HiView Pro

The instrument cannot be connected during recording (including standby operation) or analysis.

Connector : Series B receptacle

Connection destination : Computer [Windows10 (32bit/ 64bit), Windows8 (32bit/ 64bit), Windows7 (32bit/ 64bit)]

External control interface Connector : 4-pin screwless terminal block

External event input :

External event input at TTL low level (at falling edge of 1.0 V or less and when shorted) between GND terminal and EVENT IN terminal

Min. pulse width: 30 ms; rated voltage: -0.5 V to +6.0 V

External event output :

External event output item setting

Operation Pulse width

Short pulse output TTL low output at event generation between

[GND] terminal and [EVENT OUT] terminal

Low level for 10 ms or more

Long pulse output TTL low output at event generation between

[GND] terminal and [EVENT OUT] terminal

(No external event output at START event)

Low level for approx. 2.5 s

ΔV10 alarm

TTL low output at ΔV10 alarm between [GND]

terminal and [EVENT OUT] terminal

Low level while alarm occurring

; reverts to high at data reset

Environment and safety specications

Operating environment Indoors, altitude up to 3000 m (measurement category is lowered to 600 V CAT III when above 2000m), Pollution degree 2

Storage temperature and humidity

-20 to 50°C (-4 to 122°F) 80% RH or less (non-condensating)

(If the instrument will not be used for an extended period of time, remove the battery pack and store in a cool location [from -20 to 30°C (-4 to 86°F)].)

Operating temperature and humidity

0 to 50°C (32 to 122°F) 80% RH or less (non-condensating)

Dust and water resistance IP30 (EN60529)
