Hioki PW3198 Manual

9
Measurement items
Voltage
measurement items
(TIME PLOT Recording)
RMS voltage
Frequency
DC voltage
Harmonic voltage (0 to 50th order)
Inter-harmonic voltage (0.5 to 49.5th)
Total harmonic voltage distortion factor
Waveform voltage peak
Frequency (1 cycle, 10-sec)
IEC Flicker (Pst, Plt)
Harmonic voltage phase angle (0 to 50th)
High order harmonic voltage component
Voltage Unbalance factor
(Zero-phase /Negative-phase)
Current
measurement items
(TIME PLOT Recording)
RMS current
Waveform current peak
Harmonic current phase angle (0 to 50th)
Harmonic current (0 to 50th)
Inter-harmonic current (0.5 to 49.5th)
High order harmonic current component
Total harmonic current distortion factor
Current Unbalance factor
(Zero-phase /Negative-phase)
K factor
DC current (when using compatible sensor)
Power
measurement items
(TIME PLOT Recording)
Active power
Reactive power
Apparent power
Power factor
Harmonic power (0 to 50th)
Harmonic voltage-current phase angle (0 to 50th)
Active energy
Reactive energy
EVENT
measurement items
(EVENT Recording)
Transient overvoltage
Voltage swell
Voltage dip
Interruption
Inrush current
Frequency uctuations
Voltage waveform comparison
Timer
External events
Event detection using upper and lower thresholds available with other voltage, current and power measurement parameters
(excluding Integrated power, Unbalance, Inter-harmonic, Harmonic phase angle, IEC Flicker)
Basic specications
Maximum recording period 55 weeks (with repeated recording set to [1 Week], 55 iterations)
55 days (with repeated recording set to [1 Day], 55 iterations)
35 days (with repeated recording set to [OFF])
Maximum recordable events 55,000 events (with repeated recording on)
1000 events (with repeated recording off)
TIME PLOT data settings TIME PLOT interval (MAX/MIN/AVG within each interval recorded)
1s, 3s, 15s, 30s, 1m, 5m, 10m, 15m, 30m, 1h, 2h, 150 cycle (at 50Hz), 180 cycle (at 60Hz), 1200 cycle (at 400Hz)
Screen copy interval (screen shot at each interval saved to SD memory card)
OFF, 5m, 10m, 30m, 1h, 2h
Timer EVENT interval (200ms instantaneous waveform saved at each interval)
OFF, 1m, 5m, 10m, 30m, 1h, 2h
Time start and End
OFF: Start recording manually
ON: Start time and End time can be congured
Repeated recording settings (maximum 55 iterations)
OFF: Recording is not repeated
1Week: 55 weeks maximum in 1week segmentations
1Day: 55 days maximum in 1day segmentations
Repeat time
Daily Start time and End time can be congured when Repeated recording set to 1Day.
Recording items settings Power (Small): Recording basic parameters
P&Harm (Normal): Recording basic parameters and harmonics
All Data (Full): Recording P&Harm items and inter-harmonics
Memory data capacity SD memory card/ SDHC memory card 2G to 32GB
Contact your HIOKI representative for special order larger capacity cards that offer the HIOKI guarantee.
PW3198 Specications
(Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)
Input specications
Measurement circuits Single-phase 2-wire (1P2W), single-phase 3-wire (1P3W), three-phase 3-wire (3P3W2M, 3P3W3M) or three-phase 4-wire(3P4W,
3P4W2.5E) plus one extra input channel (must be synchronized to reference channel during AC/DC measurement)
Fundamental frequency
of measurement circuit
50Hz, 60Hz, 400Hz
Input channels Voltage : 4 channels (U1 to U4),
Current : 4 channels (I1 to I4)
Input methods Voltage :
Isolated and differential inputs (channels not isolated between U1, U2 and U3; channels isolated between U1 to U3 and U4)
Current : Insulated clamp-on sensors (voltage output)
Input resistance Voltage : 4MΩ ±80kΩ (differential inputs)
Current : 100kΩ ±10 kΩ
Compatible clamp sensors Units with f.s.=0.5V output at rated current input (f.s.=0.5V recommended)
Units with rate of 0.1mV/A, 1mV/A, 10mV/A, or 100mV/A
Measurement ranges
(Ch1 to Ch4 can be congured
the same way; only CH4 can be
congured separately)
Voltage measurement ranges
PW3198 current ranges
PW3198 Power ranges
(automatically congured based on current range)
Voltage measurement items Ranges
Voltage measurement 600.00V
Transient measurement 6.0000kV peak
Current range Power range (W / VA / var)
5.0000 kA 3.0000M
1.0000 kA 600.00k
500.00 A 300.00k
100.00 A 60.000k
Current range Power range (W / VA / var)
50.000 A 30.000k
10.000 A 6.0000k
5.0000 A 3.0000k
Current sensor Current range setting (A)
9660 100.00 / 50.000
9661 500.00 / 50.000
CT9667-01 (500A) 500.00 / 50.000
CT9667-01 (5kA) 5.0000k / 500.00
CT9667-02 (500A) 500.00 / 50.000
CT9667-02 (5kA) 5.0000k / 500.00
CT9667-03 (500A) 500.00 / 50.000
CT9667-03 (5kA) 5.0000k / 500.00
9669 1.0000k / 100.00
9694 50.000 / 5.0000
9695-02 50.000 / 5.0000
9695-03 100.00 / 10.000
Current sensor Current range setting(A)
CT7731 (60A) 50.000 / 5.0000
CT7731 (100A) 500.00 / 50.000
CT7736 (60A) 50.000 / 5.0000
CT7736 (600A) 500.00 / 50.000
CT7742 (600A) 500.00 / 50.000
CT7742 (2kA) 5.0000k / 500.00
9657-10 5.0000 / 500.00m
9675 5.0000 / 500.00m
