WARNING
For safe operation of this machine, read and understand all
instructions. Look for the ‘warning/caution’ symbol.
This symbol means that if you do not follow the instructions
injury can occur to the operator and damage to the
machine and floor may result.
WARNING: Risk of explosion.
Floor sanding can result in an explosive mixture of fine
dust and air. Use this floor-sanding machine only in a well-
ventilated area free from any flame, match or source of
ignition.
WARNING: Risk of fire.
Never leave the floor sander unattended with dust in the
dust bag.
WARNING: Risk of potential injury.
Moving Parts - to reduce the risk of injury, unplug the
machine before replacing abrasive sheets or carrying out
any form of adjustment or servicing.
NORTH AMERICAN SAFETY INSTRUCTIONS
WARNING: This floor sanding machine must be grounded.
This floor-sanding machine shall be grounded while in use to protect
the operator from electric shock. The machine is provided with a
three-conductor cord and a moulded three-contact grounding
type attachment plug to fit the proper grounding type receptacle.
The Green (or Green and Yellow) conductor in the cord is the
grounding wire. Never connect this wire to any pin other than the
grounding pin of the attachment plug.
This floor-sanding machine is provided with an attachment plug
as shown in sketch A. It is intended for use on a nominal 120 volt
circuit. If a properly grounded receptacle as shown in sketch A
is not available, an adaptor as shown in sketch ‘C’ should be
installed as shown in sketch B if the outlet box that houses the
receptacle is grounded. Be sure to fasten the grounding tab with a
metal faceplate screw.
MAINS CABLE WIRING - PLUG
USE & APPLICATION
This machine is intended for commercial use connected with the
laying and maintaining of wooden floors and decks.
These types of surfaces may be found both in commercial and
household environments.
SPARE PARTS
Use Hiretech genuine spare parts only for service and repair.
Use of non-approved parts will void the product warranty. See
the back cover of this manual for the terms and conditions of the
Hiretech Limited Warranty.
Hiretech reserves the right to make changes or improvements to it’s
products without prior notice.
For the latest product news and updates, spare parts, downloads
and service information visit www.hiretech.biz
ATTACHMENT PLUG
SKETCH ‘C’
METAL
SCREW
COVER OF GROUNDED
OUTLET BOX SKETCH ‘B’
ADAPTER
GROUNDING
MEANS
COVER OF GROUNDED
OUTLET BOX SKETCH ‘A’
GROUNDING PIN
CONTENTS
Warning 1
North American Safety Instructions 1
Mains Cable Wiring - Plug 1
Use & Application 1
Spare Parts 1
Specification 2
Safety 2
Set Up 2
Preparation 3
Operation 3
Floor Sanding Technique 4
Floor Types 4
Floor Sanding Technique 5
Floor Sanding Abrasive Guide 5
Service & Routine Maintenance 6
Fault Finding 8
Parts Diagram 9
Parts List 10
Circuit Diagram 10
