SPECIFICATION
The HT7-2 Hiretech Edger (Disc Floor Sander) will sand hard and
soft wood floors, cork and composition floors and any solid wood
surface that requires rapid sanding and levelling to a fine finish.
Ideal for confined areas such as closets and stair treads the HT7-2
will sand right up to the edge of a floor without damage to the base
(skirting) board. Completely self contained with a high efficiency
dust pick-up the HT7-2 is a high performance sander suitable for
professional and home owner use.
Power Supply 110/120 V 50/60 Hz
220/240 V 50/60 Hz
Off Load Current 110/120 V 8A
220/250 V 5A
Average Load Current 110/120 V 15A
220/250 V 8A
Noise 100 dBa at 1metre (3’ 3”)
Vibration 0.04 m/s² r.m.s.
Switch Bias Off, double pole.
Motor Continuous heavy duty AC/
DC self cooling 4 brush.
Motor RPM 13,000
Drum RPM 3,300
Sanding Disc 7” (178mm) dia. Metal
backed and rubber bonded.
Disc Guard: High impact ABS with bronze
bush.
Drive Hardened steel alloy pinion
and large diameter aluminium
bronze drive gear.
Moving Parts Sealed for life ball bearings.
Dust Pickup Seated oversize vacuum fan,
disposable paper dust or cloth
bag
Abrasive 178mm (7”) dia. x 22mm
(7/8“) dia. centre hole. 24 to
120 grit fibre or paper back.
Power Cable 7m (23’) Non-marking outer
insulation.
Weight Net 16.4kg (36.2lbs)
Shipping Weight 18.0kg (39.7lbs)
Shipping Dimensions 39 x 32 x 35cm
(15.45 x 12.6” x 13.8”)
Warranty 2 years
Read the following Safety and Operational notes before
using your Hiretech Floor Sander.
SAFETY
1. For safety it is recommended that a residual current circuit
breaker (ground fault interrupter) is used with this machine.
2. Check the operating voltage is correct and that the machine is
switched OFF (O) before connecting to the power supply.
3. Never attempt to lock the switch in the ON (I) position with
tape or by any other means.
4. Always disconnect from the power supply when changing the
abrasive disc, servicing the floor sander, replacing the dust
bag or leaving the machine unattended.
5. Always replace the dust bag (paper type) or empty the dust
bag (cloth type) when the dust in the bag reaches the ‘MAX’
line or when the machine is left unattended.
6. Never dispose of or empty the contents of the dust bag into a
fire or incinerator.
7. Never reuse the paper dust bag or use a non standard bag.
Cloth type bags must be in good condition with no holes.
8. Always wear a dust mask when using the floor sander,
handling the dust bag or cleaning the machine after use.
9. Wear ear protection when using the floor sander.
10. Ensure adequate ventilation of the work area to avoid the
formation of a combustible mixture of flying dust and air.
11. Never smoke when using or servicing the floor sander or
when handling the dust bag.
12. Never expose the machine to rain or damp. Always store in a
dry place.
13. Stop the floor sander immediately if damage to the machine
or abrasive disc is suspected.
14. Never allow the power cable to come into contact with the
sanding disc when the floor sander is in operation. If the
power cable becomes damaged and the inner conductors are
exposed switch the power OFF and remove the plug before
attempting to move the machine. The cable must be replaced
by an authorised agent or qualified electrician using genuine
Hiretech spare parts only.
15. Keep hands, feet and loose clothing away from all moving
parts of the machine.
16. Punch down or remove all nails, screws, tacks and other
fixings from the floor before sanding to prevent contact with
the sanding disc.
17. Never use the machine above waist height as control will be
lost.
18. Keep children and pets clear at all times.
19. If the machine should fail to operate refer to the fault finding
guide on page 8.
SET UP
Assembly and Transport
1. Always carry the floor sander by the two handles with the bag
frame in the up position and the power cable stowed around
the bag frame. Protect the sanding disc with an abrasive disc
and ensure that the clamp bolt is secure. Ensure that the floor
sander is secure and cannot move when being transported
in a vehicle. The floor sander is heavy. Take care when lifting
and carrying the machine.
2. To prepare the floor sander for use place the machine on the
floor and remove the cable from the bag frame. Check that the
cable is in good condition and that all fittings are secure.
3. Lower the dust bag support frame and fit a paper dust bag
following the instructions printed on the bag. Do not reuse or
use a non standard bag. If a cloth type bag is used ensure
that it is tied securely around the dust outlet and that the bag
is in good condition with no holes.
