HireTech HTF-2 - Htf-2 Parts List

12
PARTS LIST HTF-2
1 011600 1 Switch 220/240 Volt (Bias Off)
1 011610 1 Switch 110/120 Volt (Bias Off)
2 030425 1 Housing Switch Assembly
3 030630 1 Stop Rubber
4 030920 7 Screw
5 031870 2 Grip Hand
6 010270 5 Washer Lock
7 030640 1 Lamp Neon 110/120 Volt
7 030650 1 Lamp Neon 220/240V
8 030950 2 Lead Neon
9 101206 1 Nut Lock
10 101205 1 Strain Relief
11 030660 1 Cable Main Assembly 110 Volt (NA)
11 030670 1 Cable Main Assembly 220/240 Volt (UK)
11 030680 1 Cable Main Assembly 110 Volt (UK)
11 030690 1 Cable Main Assembly 220 Volt (EEC)
11 030700 1 Cable Main Assembly 220/240V (AUS)
12 030910 1 Tube Handle Assembly
13 962345 10 Screw
15 164508 1 Hook Cable
16 980197 1 Washer
17 920148 1 Nut
18 030930 1 Handle Cable (NA)
18 030940 1 Handle Cable
18 031000 1 Handle Cable 110 Volt (UK)
19 101220 1 Strain Relief Handle Cable
19 163804 1 Strain Relief Handle Cable (NA)
20 911046 1 Body Twist Lock
21 010210 4 Screw
22 031400 1 Base Twist Lock
23 031910 1 Nut
24 030450 1 Clamp Handle
25 030042 1 Handle Frame
26 031790 2 Pin Pivot
27 031160 2 Screw
28 031900 1 Bolt
29 031800 2 Bush Bearing
30 030222 1 Latch
31 031810 1 Screw
32 031890 1 Washer
33 031880 1 Spacer Latch Pivot
34 031820 1 Screw
35 031840 1 Spring Latch Return
36 031830 1 Cover Screw
37 031850 2 Screw
39 030550 2 Washer
46 030030 1 Housing Motor
47 030022 1 Housing Gear
48 030010 1 Housing Lower
49 031090 6 Screw
50 030270 1 Window Lamp
51 031130 16 Nut
52 031120 16 Screw
53 030360 1 Brush Set
54 030350 1 Bumper
55 030300 1 Support Bag (check Serial No.)
56 031010 4 Bolt
57 031020 4 Wing Nut
58 030390 2 Clamp Abrasive
59 030400 2 Bush
60 030370 1 Sanding Block
61 030380 1 Sanding Block Abrasive Pad
62 030790 4 Screw
63 030060 1 Retainer Wheel
64 030320 1 Housing Eccentric
65 030070 2 Wheel
67 031420 1 Exhaust Guard
68 031430 1 Ring Retainer
80 030990 1 Lead Motor
81 010750 2 Brush Shunt
82 010170 1 Brush Block Assembly
83 010190 4 Screw Pack of 4
84 010200 4 Washer
86 010220 4 Screw and Washer Set
88 010180 4 Brush Motor
89 010230 4 Brush Spring
90 032000 1 Field 110/120 Volt HTF
90 032010 1 Field 220/240 Volt HTF
91 010290 1 Baffle
92 010300 3 Screw
93 010260 2 Washer Clamp
94 010280 2 Screw
95 010600 1 Spring Load
96 010320 2 Bearing
97 010330 1 Armature 110/120 Volt
97 010340 1 Armature 220/240 Volt
98 010350 3 Key
99 010360 1 Fan Motor
100 010370 1 Gasket
101 010380 1 Plate Exhaust
102 010390 1 Fan Intake
103 010400 1 Ring Retainer
104 010410 1 Spacer Bearing
105 010420 1 Seal
106 010430 1 Ring Retainer
107 031520 1 Spacer Pulley
108 030180 1 Pulley Drive
110 010010 4 Screw
111 030090 1 Cover Motor
112 011840 1 Insert Bearing
113 031280 1 Bush Insulator
114 031070 1 Lead Ground (Earth)
115 031040 1 Lead Lamp/Ballast
116 031050 1 Lead Lamp/Twistlock
117 031060 1 Lead Ballast/Twistlock
118 030710 1 Ballast Start 220/240 Volt
Ref. PSTK Pack Description
Qty.
Ref. PSTK Pack Description
Qty.
