118 030720 1 Ballast Start 110/120 Volt
119 163838 2 Screw
120 163808 1 Grommet
121 030280 1 Plate Lamp
122 030730 1 Holder Lamp
123 030760 3 Screw
124 030750 1 Lamp
125 030740 2 Screw
126 031450 4 Screw
127 030820 7 Screw
128 031300 1 Plug Bearing
129 030480 2 Clip
130 030490 2 Clip
131 030470 1 Bearing
132 030130 1 Shaft Drive
133 030510 1 Key
134 030150 1 Belt Drive
135 030170 1 Bush Pulley
136 030190 1 Pulley Driven
137 031170 2 Screw
138 030460 3 Bearing
139 030500 1 Clip
140 030120 1 Balance Weight
141 030080 1 Holder Sanding Pad
142 030410 1 Plate Cover
143 030110 1 Bush Eccentric
144 030440 1 Cap Retaining
PARTS LIST HTF-2
145 030780 1 Screw
146 030520 2 Spring Sanding Pad
147 980629 1 Washer
148 030830 2 Screw
149 010680 1 Pin Cotter
150 030850 2 Nut
151 030860 3 Washer
152 030100 2 Pin
153 030600 2 Spring Plunger
154 030840 2 Screw
155 030770 2 Screw
156 031650 1 Knob Assembly
157 031370 1 Hook and Loop Pad
170 07038 25 Disposable Paper Dust Bag HT7/HTF
Pack 2 (box 25)
170 07040 50 Disposable Paper Dust Bag HT7/HTF
(box 50)
180 031390 1 Owners Manual & Operating Instructions
250 011740 1 Service Tool - Pinion & Pulley
Fitting/Removal
250 031490 1 Service Tool - Lever Block Holder HTF
250 031610 1 Service Tool - Jacking Bolts HTF
Special Tools (not illustrated)
13
Ref. PSTK Pack Description
Qty.
Ref. PSTK Pack Description
Qty.
FLOOR SANDER ABRASIVES
24 Grit Open Coat 01001 - - - -
24 Grit 01002 01026 01044 - -
40 Grit Open Coat - - - - -
40 Grit 01003 01027 01045 01750 -
60 Grit - - - 01751 -
80 Grit 01004 01028 01046 01752 -
100 Grit - - - - -
120 Grit 01005 01030 01048 01754 -
180 Grit - - - - 01756 -
Abrasive Pad 280G/Backing Pad - - - - 01769
HT8/DU8
FLOOR SANDER
SHEET
50/CASE
HT7/SUPER 7
EDGER DISC
FIBRE BACKED
25/CASE
HT7/SUPER 7
EDGER DISC
PAPER BACKED
25/CASE
HTF
FLOOR SANDER
SHEET
ADHESIVE BACKED
50/CASE
HTF
ABRASIVE PAD
20/CASE
Hiretech Abrasive Product Range
Hiretech recommend the following
abrasive range which are suitable
for all floor types and applications.
