Installation MACH 1000
Release
04
12/2015
9 to 10 10/100/1000 Mbit/s ports
1 + 2 or 1 to 4
99 Not present (in MAR1020)
CC 2 × combo port (SFP slot: 100/1000 Mbit/s,
alternatively twisted pair RJ45 socket:
10/100/1000 Mbit/s)
4O 2 × 2 Gigabit Ethernet ports SFP 1000 Mbit/s
4T 2 × 2 Gigabit Ethernet ports RJ45
10/100/1000 Mbit/s
OT 2 × Gigabit Ethernet port SFP 1000 Mbit/s
plus 2 × Gigabit Ethernet port RJ45
10/100/1000 Mbit/s
11 to 12 10/100 Mbit/s ports 1+ 2
a)
99 Module position empty
TT 2 × twisted pair TX, RJ45, 10/100 Mbit/s
BB 2 × Multimode FX LC 100 Mbit/s
MM 2 × Multimode FX DSC 100 Mbit/s
JJ 2 × Multimode FX MTRJ 100 Mbit/s
NN 2 × Multimode FX ST 100 Mbit/s
VV 2 × Singlemode FX DSC 100 Mbit/s
UU 2 × Singlemode FX ST 100 Mbit/s
LL 2 × Singlemode Long Haul FX DSC
100 Mbit/s
GG 2 × Singlemode Long Haul FX DSC 200 km
100 Mbit/s
ZZ 2 × SFP slot 100 Mbit/s
RR 2 × twisted pair TX, M12, 10/100 Mbit/s
FF
b
2 × Multimode FL ST 10 Mbit/s
13 to 14 10/100 Mbit/s ports 3 + 4 See 11 to 12
15 to 16 10/100 Mbit/s ports 5 + 6 See 11 to 12
17 to 18 10/100 Mbit/s ports 7 + 8 See 11 to 12
19 to 20 10/100 Mbit/s ports 9 + 10 See 11 to 12
21 to 22 10/100 Mbit/s ports 11 + 12 See 11 to 12
23 to 24 10/100 Mbit/s ports 13 + 14 See 11 to 12
25 to 26 10/100 Mbit/s ports 15 + 16 See 11 to 12
27 to 28 10/100 Mbit/s ports 17 + 18 See 11 to 12
29 to 30 10/100 Mbit/s ports 19 + 20 See 11 to 12
31 to 32 10/100 Mbit/s ports 21 + 22 See 11 to 12
33 to 34 10/100 Mbit/s ports 23 + 24 See 11 to 12
35 Temperature range S Standard
U Extended
F Extended, Conformal Coating
36 Type of power supply unit 1 C
G
L
M
Specification of types
37 Type of power supply unit 2 9 Not present
C
G
L
M
Specification of types
Position Characteristic Ident. Property
Table 1: Combination options for the device variants of the MACH 1000
