Installation MACH 1000
Release
04
12/2015
19
38 Approvals H CE, UL 508, ISA 12.12.01- Class I, Div. 2,
GL, IEC 61850, IEEE 1613 Substation, EN
50121-4 Railway (along track), NEMA TS2
T CE, UL 508, ISA 12.12.01- Class I, Div. 2,
EN 50121-4 railway (along track),
NEMA TS2, EN 50155 railway (train)
cd
39 Software variant P Professional
a. In device variants with PoE (Power over Ethernet), the first 4 ports can be twisted pair TX
RJ45 10/100 Mbit/s (short designation TT) or twisted pair TX M12 10/100 Mbit/s (short
designation RR), as desired.The other ports are freely selectable from the table. Power
supply unit 2 is a PoE power supply unit (input voltage range position 37: “G” or “M”). Power
supply unit 1 1 is freely selectable from the table.
b. Device variants with PoE or with FL ports: no “T” certification (EN 50155 railway (train))
present.
c. Rated voltage for power supply unit type G and M: 110 VDC; for power supply unit type C
and L: 36 VDC
d. The railway standard EN 50155 is only met if the PoE power is limited to 15 W.
Position Characteristic Ident. Property
Table 1: Combination options for the device variants of the MACH 1000
