1.3 Description of the device variants
The industrial ETHERNET series MICE (Modular Industrial Communication
Equipment) consists of a basic switch module and the media modules. These
devices can be managed. A basic module contains all the functions of this
industrial Switch, with the exception of the interfaces to the LAN that is
connected. Pluggable media modules provide these interfaces. They differ
with regard to the number of interfaces and the media type for connecting
segments. An expansion module enables you to add 2 slots for media
modules to the basic module.
12 Specifications A CE, UL 508, ISA 12.12.01 Class I Division 2
B CE, UL 508, ISA 12.12.01 Class I Division 2, GL,
ATEX 100a Zone 2
E CE, UL 508, GL, EN 50121-4
H CE, UL 508, ISA 12.12.01 Class I Division 2, GL,
IEC 61850-3, IEEE 1613,EN 50121-4
S CE, UL 508, GL, IEC 61850-3, IEEE 1613,
EN 50121-4
Y CE, UL 508
ZCE
13 Software variant E Enhanced
P Professional
Product code Product features
Modular switch with gigabit ports
8 × 100 Mbit Ethernet ports
2 × 1000 Mbit Ethernet ports
Temperature range standard (0 °C to 60 °C)
Voltage range 18 VDC to 32 VDC
Specifications CE, UL 508, ISA 12.12.01 Class I
Division 2
Software version enhanced
Table 2: Example for product code: MS30-0802SAAE
Position Attribute Ident. Feature
Table 1: Combination options of the MS20/MS30 device versions
MS30- 08 02 S A A E
MS30- =
08 =
02 =
S =
A =
A =
E =
