20
Installation MS20/MS30
Release 11 07/2013
8 - Terminal block (power 1)
9 - DIP switch
10 - USB port
11 - V.24 port
12 - MICE MS20/30 switch basic module with 18 to 32 VDC voltage range
Figure 4: Connections of the MS20-.../MS30-...E on the bottom of the device
1 - Terminal block 6-pin for power and signal contact
2 - DIP switch
3 - USB port
4 - V.24 port
5 - MICE MS20/30-...E... switch basic module with 18 to 60 VDC
voltage range / 6-pin
4
3
2
1
5
