Installation MS20/MS30
Release 11 07/2013
65
6 to 7 1st port
(medium/connector)
T1 Twisted pair (TX) / RJ45
T5 Twisted pair (TX) / M12
M2 Multi-mode FX DSC (100 Mbit/s)
M3 Multi-mode FX MTRJ (100 Mbit/s)
M4 Multi-mode FX ST (100 Mbit/s)
S2 Single-mode FX DSC (100 Mbit/s)
S4 Single-mode FX ST (100 Mbit/s)
L2 Single-mode Long Haul FX DSC (100 Mbit/s)
G2 Single-mode Long Haul FX DSC 200km (only
100 Mbit/s)
F4 Multi-mode FL ST (10 Mbit/s)
P9 POF FX SCRJ (100 Mbit/s)
O7 Combo port Gigabit Ethernet (SFP 1000 Mbit/s)
A8 AUI Sub-D
Z6 Fiber optic / SFPslot (100 Mbit/s)
IO 4 digital inputs, 4 digital outputs
8 to 9 2nd port
(medium/connector)
... See items 6 to 7
10 to 11 3rd port
(medium/connector)
... See items 6 to 7
99 Empty
12 to 13 4th port
(medium/connector)
... See items 6 to 7
99 Empty
14 Temperature range S Standard: operation 0 °C ... +60 °C;
storage −40 °C to +70 °C
T Extended: operation −40 °C ... +70 °C;
storage −40 °C to +85 °C
E Extended: operation −40 °C ... +70 °C;
storage −40 °C to +85 °C,
with Conformal Coating
15 Certifications A CE, UL 508, ISA 12.12.01 Class I Division 2
B CE, UL 508, ISA 12.12.01 Class I Division 2, GL,
ATEX 100a Zone 2
E CE, UL 508, GL, EN 50121-4
H CE, UL 508, ISA 12.12.01 Class I Division 2, GL,
IEC 61850-3, IEEE 1613,EN 50121-4
S CE, UL 508, GL, IEC 61850-3, IEEE 1613,
EN 50121-4
Y CE, UL 508
ZCE
Item Characteristic feature Ident. Property
Table 23: Combination possibilities of the MM20/MM30 media module variants
