Installation OCTOPUS OS20/OS24 Unmanaged
Release 07 07/2014
33
 Dimension drawings
Figure 3: Dimensions
52,8 mm
2.08 inch
171,8 mm
6.77 inch
183,8 mm
7.24 inch
188,5 mm
7.43 inch
120 mm
4.73 inch
