34
Installation OCTOPUS OS20/OS24 Unmanaged
Release 07 07/2014
 EMC and immunity
 Network range
EMV interference immunity
IEC/EN 61000-4-2 Electrostatic discharge
Contact discharge
Air discharge
6 kV
8 kV
IEC/EN 61000-4-3 Electromagnetic field
80 MHz ... 2700 MHz 20 V/m
IEC/EN 61000-4-4 Fast transients (burst)
AC/DC supply connection
Data line
2 kV
4 kV
IEC/EN 61000-4-5 Voltage surges
DC supply connection
Data line
line/line
line/ground
1 kV
2 kV
1 kV
IEC/EN 61000-4-6 Line-conducted interference voltages
150 kHz ... 80 MHz 10 V
EN 61000-4-9 Impulse-shaped magnetic fields 300 A/m
EMC emitted interference
EN 55022 Class A Yes
FCC 47 CFR Part 15 Class A Yes
German Lloyd Classification + Construction Guidelines VI-7-3 Part 1
Ed.2001
Yes
Stability
Vibration IEC 60068-2-6 Test FC test level according to IEC 61131-2 Yes
Germanischer Lloyd Guidelines for the Performance of Type
Tests Part 1
Yes
IEC 870-2-2 table 3 normal installation according to EN
61850-3
Yes
EN 61373, Category 1, Class A (broadband noise),
installation in acc. with EN 50155
Yes
Shock IEC 60068-2-27 Test Ea test level according to IEC 61131-2 Yes
IEC 870-2-2 table 3 normal installation according to EN
61850-3
Yes
EN 61373, Category 1, Class A (broadband noise),
installation in acc. with EN 50155
Yes
TP port
Length of a twisted pair segment max. 100 m/328 ft (for cat5e cable)
Table 14: TP port 10BASE-T / 100BASE-TX / 1000BASE-T
