Installation OCTOPUS OS20/OS24 Unmanaged
Release 07 07/2014
35
 Power consumption/power output
 Scope of delivery
 Order numbers/product description
Device name and product
code
Maximum power consumption Power output
OS20-001000T5T5TAFUHB 5.8 W 19.8 Btu (IT)/h
OS20-001000T5T5TNEUHB 12 W 41 Btu (IT)/h
OS24-081000T5T5TFFUHB 80 W 68 Btu (IT)/h
OS24-081000T5T5TNEUHB 80 W 68 Btu (IT)/h
Device name and product code Scope of delivery
OS20-001000T5T5TAFUHB Octopus device
Connector ELWIKA 5012 PG7 for supply voltage
Note: Connector ELWIKA 5012 PG7 (933 175-100)
supports a temperature range from −25°C to +70°C. Thus it
can restrict the operation location for the overall system.
You can obtain special connectors with protection class
IP54 and an extended temperature range on request.
Installation user manual
OS24-081000T5T5TFFUHB Octopus device
Ferrite with key
Installation user manual
OS20-001000T5T5TNEUHB
OS24-081000T5T5TNEUHB
Octopus device
Installation user manual
Device name and product code Order number
OS20-001000T5T5TAFUHB 942 025-001
OS20-001000T5T5TNEUHB 942 025-002
OS24-081000T5T5TFFUHB 942 025-003
OS24-081000T5T5TNEUHB 942 025-004
Table 15: Device types: product code, order number
