12
Installation OS20/OS30
Release 03 06/2015
Position Characteristic Characteri
stic value
Description
1 to 4 Product OS20 IP67 Switch without gigabit ports
OS30 IP67 Switch with gigabit ports
5 - (hyphen) -
6 to 7 Number of special
ports
00 0 ×
8 to 9 Number of 100 Mbit/s
ports:
08 8 ×
10 10 ×
10 to 11 Number of
1000 Mbit/s ports
00 0 ×
02 2 ×
12 to 13 1. Uplink port
(medium/connector)
1M M-FAST SFP-MM / LC / EEC / variant 1
1S M-FAST SFP-SM / LC / EEC / variant 1
1P M-FAST SFP-SM+ / LC / EEC / variant 1
1L M-FAST SFP-LH / LC / EEC / variant 1
1A M-SFP-SX / LC / EEC / variant 1
1B M-SFP-LX / LC / EEC / variant 1
1C M-SFP-LH / LC / EEC / variant 1
1D M-SFP-LH+ / LC / EEC / variant 1
4M M-FAST SFP-MM / LC / EEC / variant 4
4S M-FAST SFP-SM / LC / EEC / variant 4
4P M-FAST SFP-SM+ / LC / EEC / variant 4
4L M-FAST SFP-LH / LC / EEC / variant 4
4A M-SFP-SX / LC / EEC / variant 4
4B M-SFP-LX / LC / EEC / variant 4
4C M-SFP-LH / LC / EEC / variant 4
4D M-SFP-LH+ / LC / EEC / variant 4
14 to 15 2. Uplink port
(medium/connector)
See positions 12 to 13
16 Temperature range T −40 °F ... +158 °F (−40 °C ... +70 °C )
17 Voltage range incl.
max. tolerances
R 16.8 VDC ... 45.0 VDC
18 Approvals E CE, C-Trick, E1, EN 50155, EN 50121-4
(railway, trackside), FCC
19 Software variant P Professional
Table 1: Combination options for the device variants of OS20/OS30
