Installation RSPM
Release
15
04/2018
17
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the Configurator which is
available in the Belden E-Catalog (www.e-catalog.beldensolutions.com) on
the web page of the device.
Item Characteristic Character
istic value
Description
1 ... 4 Product RSPM Rail Switch Power Media Module
5 Data rate 2 10/100 Mbit/s
6 Hardware type 0 Standard
2 Standard with PoE(+)
7 (hyphen) –
8 ... 10 Port configuration
Part A
4Z6 4 × SFP slot for 100 Mbit/s F/O connections
4T1 4 × RJ45 socket for 10/100 Mbit/s twisted pair
connections
11 ... 13 Port configuration
Part B
4Z6 4 × SFP slot for 100 Mbit/s F/O connections
4T1 4 × RJ45 socket for 10/100 Mbit/s twisted pair
connections
14 Temperature range S Standard +32 °F ... +140 °F (0 °C ...
+60 °C)
T Extended −40 °F ... +158 °F
(−40 °C ... +70 °C)
E Extended with
Conformal Coating
−40 °F ... +158 °F
(−40 °C ... +70 °C)
15 ... 16 Certificates and
declarations
You will find detailed information on the certificates and
declarations applying to your device in a separate overview.
See table 2 on page 18.
17 ... 18 Customer-specific
version
HH Hirschmann Standard
19 Hardware
configuration
S Standard
20 Software configuration 9 without configuration
21 ... 25 Software version 99.9. without software
26 ... 27 Maintenance 99 without software
Table 1: Device name and product code
