22
Installation RSPM
Release
15
04/2018
1.4.3 Support of PoE(+)
See “Device name and product code” on page 17.
The 10/100 Mbit/s twisted pair port allows you to connect network
components as a PoE voltage sink according to the standard IEEE 802.3
10BASE-T/100BASE-TX and IEEE 802.3af/at.
With the presence of the PoE power supply, a separate power supply for the
connected device is unnecessary.
The PoE power is supplied via the wire pairs transmitting the signal (phantom
voltage).
The individual ports (joint PoE voltage) are not electrically insulated from
each other.
Maximum power available to PoE end devices in total:
124 W
Maximum power available to a media module:
62 W
Note: Connect only PoE-supplier devices whose data connections are
located in the interior of the building and are specified as SELV circuits.
The PoE support complies with the following technical standards:
In accordance with IEEE 802.3af and IEEE 802.3at:
Endpoint PSE
Alternative A.
Technical
standard
Description
IEEE 802.3af Brief description PoE
Classes max. Powered Device (PD) class 0 (15,4 W)
IEEE 802.3at Brief description PoE+
Classes max. Powered Device (PD) class 4 (30 W)
Table 4: PoE support: technical standards
