1.5. Adjusting the position of the driver unit floor/windscreen flaps.
If the driver node is set to climatization, the position of the floor/windscreen flaps can be adjusted using the
(7) key.
When the position of the floor/windscreen vents is adjusted manually, the following display will appear on
the screen:
Air to driver’s feet Air to screen. Air to feet and screen
Under certain conditions the system will not allow manual change of the flaps position, as it is the case
when Demist function is working. If Demist is ON, the flap will be in Windshield position and it can’t be manual-
ly modified.
1.6. Setting the driver climate unit to automatic.
If the position of the driver unit recirculation flaps, floor/windscreen flaps, or the speed of the defroster are
adjusted manually, or if the pre-heater, defroster or ECO mode are manually switched on, the driver climate
unit changes to manual mode, and the LED located next to the (3) key goes off.
By pressing driver unit key (3) all the driver unit controls are switched back to automatic and, if the
passenger node is also set to automatic, the automatic screen appears as shown below.
Automatic screen.
1.7. Switching the passenger climatization unit on and off.
The system remembers the state before the last vehicle shut down. When starting again, the system will fix
the SET before to that last disconnection.
It is possible to switch on the climatization system by pressing key (15) even though the engine is
stopped, providing the ignition is on. Since in this situation the battery is not charging, in order to prevent it
going flat, it will not be possible to switch on the fan and you will only be able to have heating with the convec-
tor system.
The passenger node can be switched off manually by holding down key (15) for 2 seconds. In this
case, the part of the screen corresponding to the passenger unit will remain blank.
