-209-

CHASSIS

- 209-

No. Part Name Qty Remarks

Gear shifting support 1

Hexagon flange bolt M6×16 2

Gear shift rod II 1

Gearshift tie assy II 1

Hexagon flange bolt M6×16 1

Washer Φ6×Φ12×1.6 1
