-78-
SPECIFICATIONS
CHASSIS
Lubrication points Lubricant
Lip of oil seal (full) Light lithium-base grease
lithium-base grease
Steering shaft (upper end ,lower end) Light lithium-base grease
Ball connection of steering pushing rod Light lithium-base grease
Front wheel fork(ball-shaped joint) Light lithium-base grease
Front wheel bearing Grease used for bearing
Front & rear brake Light lithium-base grease
Dust-proof ring of brake Light lithium-base grease
Joint of front brake cable Light lithium-base grease
Front brake lever axle and rear brake lever axle Light lithium-base grease
Adjusting nut and pin of front brake cable Light lithium-base grease
Adjusting nut and pin of rear brake cable Light lithium-base grease
Rear brake pedal pivot and brake pedal axle hole Light lithium-base grease
Throttle rotating frame shaft and end section of throttle cable Light lithium-base grease
Reverse gear lever pivot Light lithium-base grease
Connection bolt of rear wheel fork and frame, rear wheel fork
bearing
Light lithium-base grease
Rubber sleeve and rear wheel fork Seal gum
Rear shock absorber bushing Light lithium-base grease
