Hisun HS250UTV - Seat

-229-
CHASSIS
- 229-
SEAT
No. Part Name Qty Remarks
Removing the seat
1 Seat connection assy. 2
2 Back rest 2
3 Seat cushion 2
4 Hexagon bolt M8×25 22
5 Washer Φ8×Φ16×1.6 14
6 Rubber plug Φ19×Φ25×10 14
7 Seat mounting board 2
8
Slide rail（R）
2
9
Slide rail（L）
2
10 Hexagon socket head bolt M8×20 16
11 Rubber thick gasket Φ24×15 2
