INSTALLING THE RADIATOR
1. Fill:
• cooling system
Start engine when pour full the refrigerating fluid,
loose the exhaust nut on the pipe, the water level
will get lower at this time, Supply the refrigerating
fluid until the water level stop to change, then
screw the exhaust nut, cover the water tank lid.
The water tank inspection is finished. .
2. Check:
• cooling system
Leaks
Repair or replace any faulty part.
CHASSIS
- 229-
SEAT
No. Part Name Qty Remarks
Removing the seat
1 Seat connection assy. 2
2 Back rest 2
3 Seat cushion 2
4 Hexagon bolt M8×25 22
5 Washer Φ8×Φ16×1.6 14
6 Rubber plug Φ19×Φ25×10 14
7 Seat mounting board 2
8
Slide rail（R）
2
9
Slide rail（L）
2
10 Hexagon socket head bolt M8×20 16
11 Rubber thick gasket Φ24×15 2
