-247-

ELECTRICAL COMPONENTS

- 247 -

STARTER MOTOR

No. Part Name Qty Remarks

Removing the starter motor

Flange bolt

Starter motor assy.

1 / 1

Remove the parts in the order listed

CHARGING SYSTEM

CIRCUIT DIAGRAM（

See 293 page）
