8-38 Periodic Maintenance and Adjustment
Wheel removal
Loosen the wheel nuts .
Elevate the vehicle and place a suitable
stand under the frame.
Remove the nuts from the wheel.
Remove the wheel.
1. Nut（×4）
Wheel installation
1. Install the wheel and the nuts.
NOTE:
● The arrow mark on the tire must
point toward the rotating direction of the
wheel.
● Tapered nuts are used for both the front
and rear wheels. Install the nut with its
tapered side towards the wheel.
1. Arrow mark
