27
22” TFT TV Service Manual
36 47 38 51 39 SC3_IN_R IN LV SCART 3 input, right
37 46 37 50 38 SC3_IN_L IN LV SCART 3 input, left
38 45 - 49 37 ASG4 AHVSS Analog Shield Ground 4
39 44 - 48 36 SC4_IN_R IN LV SCART 4 input, right
40 43 - 47 35 SC4_IN_L IN LV SCART 4 input, left
41 - - 46 - NC LV or AHVSS Not connected
42 42 36 45 34 AGNDC OBL Analog reference voltage
43 41 35 44 33 AHVSS OBL Analog ground
- - - 43 - AHVSS OBL Analog ground
- - - 42 - NC LV Not connected
- - - 41 - NC LV Not connected
44 40 34 40 32 CAPL_M OBL Volume capacitor MAIN
45 39 33 39 31 AHVSUP OBL Analog power supply 8V
46 38 32 38 30 CAPL_A OBL Volume capacitor AUX
47 37 31 37 29 SC1_OUT_L OUT LV SCART output 1, left
48 36 30 36 28 SC1_OUT_R OUT LV SCART output 1, right
49 35 29 35 27 VREF1 OBL Reference ground 1
50 34 28 34 26 SC2_OUT_L OUT LV SCART output 2, left
51 33 27 33 25 SC2_OUT_R OUT LV SCART output 2, right
52 - - 32 - NC LV Not connected
53 32 - 31 24 NC LV Not connected
54 31 26 30 23 DACM_SUB OUT LV Subwoofer output
55 30 - 29 22 NC LV Not connected
56 29 25 28 21 DACM_L OUT LV Loudspeaker out, left
57 28 24 27 20 DACM_R OUT LV Loudspeaker out, right
58 27 23 26 19 VREF2 OBL Reference ground 2
59 26 22 25 18 DACA_L OUT LV Headphone out, left
60 25 21 24 17 DACA_R OUT LV Headphone out, right
- - - 23 - NC LV Not connected
- - - 22 - NC LV Not connected
61 24 20 21 16 RESETQ IN OBL Power-on-reset
62 23 - 20 15 NC LV Not connected
63 22 - 19 14 NC LV Not connected
64 21 19 18 13 NC LV Not connected
65 20 18 17 12 I2S_DA_IN2 IN LV I
2
S2-data input
66 19 17 16 11 DVSS OBL Digital ground
- - - 15 - DVSS OBL Digital ground
- - - 14 - DVSS OBL Digital ground
67 18 16 13 10 DVSUP OBL Digital power supply 5V
- - - 12 - DVSUP OBL Digital power supply 5V
- - - 11 - DVSUP OBL Digital power supply 5V
68 17 15 10 9 ADR_CL OUT LV ADR clock
11.21. DS90C385
11.21.1. General Description
The DS90C385 transmitter converts 28 bits of LVCMOS/LVTTL data into four LVDS (Low Voltage
Differential Signaling) data streams. A phase-locked transmit clock is transmitted in parallel with the data
streams over a fifth LVDS link. Every cycle of the transmit clock 28 bits of input data are sampled and
transmitted. At a transmit clock frequency of 85 MHz, 24 bits of RGB data and 3 bits of LCD timing and
control data (FPLINE, FPFRAME, DRDY) are transmitted at a rate of 595 Mbps per LVDS data channel.
Using a 85 MHz clock, the data throughput is 297.5 Mbytes/sec. Also available is the DS90C365 that
converts 21 bits of LVCMOS/LVTTL data into three LVDS (Low Voltage Differential Signaling) data
streams. Both transmitters can be programmed for Rising edge strobe or Falling edge strobe through a
dedicated pin. A Rising edge or Falling edge strobe transmitter will interoperate with a Falling edge strobe
Receiver (DS90CF386/DS90CF366) without any translation logic.
The DS90C385 is also offered in a 64 ball, 0.8mm fine pitch ball grid array (FBGA) package which
provides a 44 % reduction in PCB footprint compared to the TSSOP package. This chipset is an ideal
means to solve EMI and cable size problems associated with wide, high-speed TTL interfaces.
11.21.2. Features
• 20 to 85 MHz shift clock support
• Best–in–Class Set & Hold Times on TxINPUTs
• Tx power consumption <130 mW (typ) @85MHz Grayscale
• Tx Power-down mode <200µW (max)
• Supports VGA, SVGA, XGA and Dual Pixel SXGA.
• Narrow bus reduces cable size and cost
