x RANDOM and SEQUENTIAL READ Modes
x Self-Timed Programming Cycle
x Automatic Address Incrementing
x Enhanced ESD/Latch-Up Protection
x More than 1 Million Erase/Write Cycles
x More than 40-Year Data Retention
7.3 Absolute Maximum Ratings
7.4 Pinning
8. CLASS AB STEREO HEADPHONE DRIVER TDA1308
8.1. General Description
The TDA1308 is an integrated class AB stereo headphone driver contained in an SO8
or a DIP8 plastic package. The device is fabricated in a 1 mm CMOS process and has
been primarily developed for portable digital audio applications. It gets its input from two
analog audio outputs (DACA_L and DACA_R) of MSP 34x0G. The gain of the output is
adjustable by the feedback resistor between the inputs and outputs.
8.2 Features
x Wide temperature range
x No switch ON/OFF clicks
x Excellent power supply ripple rejection
x Low power consumption
x Short-circuit resistant
x High performance
x High signal-to-noise ratio
