32PD7800/42PD7800 (PW2)
PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety.
Before replacing any of there components,read carefully,the CAUTION FOR SAFETY of this Service Manual.
Don't degrade the safety of the receiver through improper servicing.
SYMBOL PART SYMBOL PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
C124 AD00415R EL CHIP 47MF 6.3V C261 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C125 AD00441R EL CHIP 100MF 16V C262 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C127 0893175R CAPACITOR CHIP 1000PF +-5% 50V C263 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C130 0893179R CAPACITOR CHIP 0.1MF +-10% 16V C264 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C131 0893179R CAPACITOR CHIP 0.1MF +-10% 16V C265 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C132 AD00436R EL CHIP 10MF 16V C266 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C1A0 0893222R CAPACITOR CHIP 0.01MF +-10% 50V C267 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C1A1 AD00436R EL CHIP 10MF 16V C268 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C1A2 AD00415R EL CHIP 47MF 6.3V C269 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C1A3 0893222R CAPACITOR CHIP 0.01MF +-10% 50V C270 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C1A4 0893222R CAPACITOR CHIP 0.01MF +-10% 50V C271 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C1A5 08003652 EL 2200MF 6.3V C272 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C1A6 0893222R CAPACITOR CHIP 0.01MF +-10% 50V C273 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C1A7 0893222R CAPACITOR CHIP 0.01MF +-10% 50V C274 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C1A8 AD00479R EL CHIP 10MF 50V C275 AD00629R EL CHIP 10MF 16V
C1C1 AD00441R EL CHIP 100MF 16V C276 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C1C2 AD00476R EL CHIP 2.2MF 50V C277 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C201 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C278 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C202 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C279 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C205 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C280 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C206 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C281 AA01101R CAPACITOR CHIP 1MF +-10% 10V
C209 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C282 0893179R CAPACITOR CHIP 0.1MF +-10% 16V
C210 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C283 AD00658R EL CHIP 100MF 50V
C213 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C284 0893179R CAPACITOR CHIP 0.1MF +-10% 16V
C214 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C285 AD00658R EL CHIP 100MF 50V
C217 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C286 0893179R CAPACITOR CHIP 0.1MF +-10% 16V
C218 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C287 AD00632R EL CHIP 47MF 16V
C221 AD00421R EL CHIP 470MF 6.3V C288 AA00931R CAPACITOR CHIP 1MF +-10% 10V
C222 AD00629R EL CHIP 10MF 16V C289 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C223 AD00629R EL CHIP 10MF 16V C290 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C224 AA00934R CAPACITOR CHIP 2.2MF +-10% 10V C291 AA01144R CAPACITOR CHIP 1MF +-10% 16V
C225 AA00934R CAPACITOR CHIP 2.2MF +-10% 10V C292 AA01144R CAPACITOR CHIP 1MF +-10% 16V
C226 AD00629R EL CHIP 10MF 16V C293 AD00658R EL CHIP 100MF 50V
C227 AD00632R EL CHIP 47MF 16V C295 AD00629R EL CHIP 10MF 16V
C228 0893179R CAPACITOR CHIP 0.1MF +-10% 16V C296 0893179R CAPACITOR CHIP 0.1MF +-10% 16V
C238 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C297 AA01144R CAPACITOR CHIP 1MF +-10% 16V
C239 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C2A0 AA00937R CAPACITOR CHIP 10MF +-10% 10V
C240 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C2A1 AA00937R CAPACITOR CHIP 10MF +-10% 10V
C241 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C2A2 AA00699R CAPACITOR CHIP 10MF +-10% 16V
C242 AD00421R EL CHIP 470MF 6.3V C2A3 AA00699R CAPACITOR CHIP 10MF +-10% 16V
C243 AD00421R EL CHIP 470MF 6.3V C2A4 AA00699R CAPACITOR CHIP 10MF +-10% 16V
C244 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C2A5 AA00699R CAPACITOR CHIP 10MF +-10% 16V
C245 AA00822R CAPACITOR CHIP 1000PF +-5% 50V C301 AD00658R EL CHIP 100MF 50V
C248 AD00629R EL CHIP 10MF 16V C302 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C249 AA00931R CAPACITOR CHIP 1MF +-10% 10V C303 AD00632R EL CHIP 47MF 16V
C250 AD00629R EL CHIP 10MF 16V C304 0893117R CAPACITOR CHIP 22PF +-5% 50V
C251 AA01101R CAPACITOR CHIP 1MF +-10% 10V C306 0893113R CAPACITOR CHIP 10PF +-0.25PF 50V
C252 AA00931R CAPACITOR CHIP 1MF +-10% 10V C309 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C253 AD00629R EL CHIP 10MF 16V C310 0893211R CAPACITOR CHIP 1500PF +-10% 50V
C254 AA01101R CAPACITOR CHIP 1MF +-10% 10V C311 0893179R CAPACITOR CHIP 0.1MF +-10% 16V
C255 AA00931R CAPACITOR CHIP 1MF +-10% 10V C312 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C256 AA01101R CAPACITOR CHIP 1MF +-10% 10V C313 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C257 AA00931R CAPACITOR CHIP 1MF +-10% 10V C314 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C258 AA01101R CAPACITOR CHIP 1MF +-10% 10V C315 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C259 AA00931R CAPACITOR CHIP 1MF +-10% 10V C316 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
C260 AA01101R CAPACITOR CHIP 1MF +-10% 10V C317 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
