PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety.
Before replacing any of there components,read carefully,the CAUTION FOR SAFETY of this Service Manual.
Don't degrade the safety of the receiver through improper servicing.
NOTE : This parts list is applied to the products mode in Japan.
ABBREVIATIONS Capacitors���������CD:Ceramic Disk, PF:Polyester Film, EL:Electrolytic, PP:Polypropylene,
PR:Paper, TA:Tantalum, TM:Trimer.
Resistors����������CF:Carbon film, WW:Wire Would, FR:Fuse Resistor, MG:Metal Glazzed,
VR:Variable resistor, CC:Carbon Composition, MF:Metal Oxide Film.
Semiconductors����TR:Transistor, DI:Diode, ZD:Zener Diode, VA:Varistor, TH:Thermistor.
SYMBOL PART SYMBOL PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
#011A 86994102 SCREW BT BIND HEAD 3X10 #70 QJ01531 STAND ASS'Y
#013 4525404 SCREW M3X10 T #701 4527829 BOLT M6X18 WITH WASHER
#01A QD39256 BEZEL ASS'Y (DARK SILVER) (for TA) #71 ND00853 STAND SUPPORT
#01C QD39254 BEZEL ASS'Y (LIGHT SILVER) (for TA-S) #72 4527828 BOLT M6X40 WITH WASHER
#023 4525404 SCREW M3X10 T #80 QA02874 BACK COVER
#025 4525404 SCREW M3X10 T #801 3705264 CABLE CLAMP
#027 86994102 SCREW BT BIND HEAD 3X10 #803 PH31101 BACK COVER GRIP
#029 4525401 SCREW M3X8 #804 4518383 SCREW M4X8
#041 4518276 SCREW M3*8 DT (BLACK) #805 MJ03131 SCREW D3 4X10 BIND CP-GRIP
#05A QL25501 EXTEND LABEL #806 4520232 SCREW 4X16 DT
#07 KS09081 FRONT FILTER #807 QL23872 SPEAKER LABEL
#103 4522885 SCREW 3X8 CE CP-GRIP #809 4527829 BOLT M6X18 WITH WASHER
#105 PC05783 POWER BUTTON #811 MJ02101 SCREW 6X12
#107 PC05792 POWER BUTTON COVER #813 QL21001 AC LABEL
#115 MJ00926 SCREW M3X12 #815 QL23981 KEY SW LABEL
#123 MJ02993 SCREW M3X8 3P CP-GRIP #817 QL21403 TEMP CAUTION LABEL
#125 4341293 SCREW M3X10 CP-GRIP #821A QL24253 FORMATER LABEL
#127 MJ02993 SCREW M3X8 3P CP-GRIP #850 QN04971 ARROW MARK LABEL
#129 4522885 SCREW 3X8 CE CP-GRIP A11 JP08051 PWB ASS'Y AUDIO
#131 4522885 SCREW 3X8 CE CP-GRIP A11 JP08081 PWB ASS'Y VIDEO
#201A NJ08552 CONTROL BUTTON HOLDER ASS'Y A21 JP08061 PWB ASS'Y JOINT/SWIVEL
#205 86994102 SCREW BT BIND HEAD 3X10 A21 JP08101 PWB ASS'Y TUNER
#213 MJ02993 SCREW M3X8 3P CP-GRIP A31 JP08071 PWB ASS'Y FILTER
#223 MJ02993 SCREW M3X8 3P CP-GRIP A31 JP08121 PWB ASS'Y HDMI
#225 MJ02993 SCREW M3X8 3P CP-GRIP A41 CS00873 FORMATER UNIT HCP223 ASS'Y
#230 MJ03351 SCREW D-SUB C001 AA01101R CAPACITOR CHIP 1MF +-10% 10V
#303 MJ02722 SCREW M4X10 AL-TI CP-GRIP C001 0800324R EL 100MF 6.3V
#305 4520882 SCREW M3 WITH WASHER C002 AA01101R CAPACITOR CHIP 1MF +-10% 10V
#307 4341291 SCREW M3X10 C002 02441712 CD 0.01MF +80-20% 50V
#31 MM00181 GRIP JOINT(CARTON BOX) C003 AA01101R CAPACITOR CHIP 1MF +-10% 10V
#315 86994102 SCREW BT BIND HEAD 3X10 C101 AD00476R EL CHIP 2.2MF 50V
#325 MJ02993 SCREW M3X8 3P CP-GRIP C103 08003262 EL 100MF 16V
#327 4518275 SCREW M3X6 DT C104 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
#409 MJ02981 SCREW PAN HEAD M5X16 WITH WASHER C105 08002942 EL 10MF 50V
#411 4520232 SCREW 4X16 DT C106 08002942 EL 10MF 50V
#413 4522885 SCREW 3X8 CE CP-GRIP C107 08003652 EL 2200MF 6.3V
#415 4522885 SCREW 3X8 CE CP-GRIP C108 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
#419 MN06421 EDGE COVER C109 AD00436R EL CHIP 10MF 16V
#421 MJ02722 SCREW M4X10 AL-TI CP-GRIP C110 AD00415R EL CHIP 47MF 6.3V
#422 8815126 WASHER LOCKING 4 C111 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
#509 4518275 SCREW M3X6 DT C112 0893134R CAPACITOR CHIP 390PF +-5% 50V
#521 4519501 SCREW T 3*10 B C113 0893122R CAPACITOR CHIP 47PF +-5% 50V
#523 MN03551 AIR FILTER C114 AD00436R EL CHIP 10MF 16V
#525 MN03556 AIR FILTER C116 AD00436R EL CHIP 10MF 16V
#601 4522885 SCREW 3X8 CE CP-GRIP C118 AD00416R EL CHIP 100MF 6.3V
#603 4519501 SCREW T 3*10 B C119 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
#611 4522885 SCREW 3X8 CE CP-GRIP C121 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
#613 4522885 SCREW 3X8 CE CP-GRIP C122 0893222R CAPACITOR CHIP 0.01MF +-10% 50V
