Hitachi 53SDX20BB - Page 19

19
SELECT
MENU  
FLEX CONT 480i
86 YH-LTI 01 93 CH-CTI 01 95 Y-CRG 00 64 YNR-IN 04 73 CNR-IN 04 80 YNRPAS 00 88 CNRPAS 02 40 READ-F 0F 55 LINE-I 00
480i mode
FLEX CONT 480P
86 YH-LTI 01 93 CH-CTI 01 95 Y-CRG 00 64 YNR-IN 04 73 CNR-IN 04 80 YNRPAS 00 88 CNRPAS 02 40 READ-F 0F 55 LINE-I 00
480P mode
FLEX CONT 1080i
86 YH-LTI 00 93 CH-CTI 01 95 Y-CRG 00 64 YNR-IN 04 73 CNR-IN 04 80 YNRPAS 00 88 CNRPAS 02 40 READ-F 0F 55 LINE-I 00
1080i mode
FLEX CONT 720P
86 YH-LTI 01 93 CH-CTI 01 95 Y-CRG 00 64 YNR-IN 04 73 CNR-IN 04 80 YNRPAS 00 88 CNRPAS 02 40 READ-F 0F 55 LINE-I 00
720P mode
FLEX CONT SPLIT
86 YH-LTI 01 93 CH-CTI 01 95 Y-CRG 00 64 YNR-IN 04 73 CNR-IN 04 80 YNRPAS 00 88 CNRPAS 02 40 READ-F - - 55 LINE-I 00
SPLIT mode
CH U/D, INPUT
FLEX CONT NTSC
86 YH-LTI 01 93 CH-CTI 01 95 Y-CRG 00 64 YNR-IN 04 73 CNR-IN 04 80 YNRPAS 00 88 CNRPAS 02 40 READ-F 0F 55 LINE-I 00
NTSC/SINGLE/SURF/STROBE mode
SELECT SELECT SELECT SELECT
SELECT
FLEX CONT 480i
65 YNRRDC 01 74 CNRRDC 00 89 CNR-0 00 27 FRMBRT 60 11 MVW-PH 07 18 SVW-PH 07 14 MHS-HP 0F 21 SHS-HP 0F 23 V-POS 1F 50 HD-POS 3F
480i mode
FLEX CONT 480P
65 YNRRDC 01 74 CNRRDC 00 89 CNR-0 00 27 FRMBRT 60 11 MVW-PH 05 18 SVW-PH 05 14 MHS-HP 0F 21 SHS-HP 0F 23 V-POS 1F 50 HD-POS 3F
480P mode
FLEX CONT 1080i
65 YNRRDC 00 74 CNRRDC 00 89 CNR-0 00 27 FRMBRT 60 11 MVW-PH 04 18 SVW-PH 04 14 MHS-HP 0F 21 SHS-HP 0F 23 V-POS 1F 50 HD-POS 3F
1080i mode
FLEX CONT 720P
65 YNRRDC 00 74 CNRRDC 00 89 CNR-0 00 27 FRMBRT 60 11 MVW-PH 06 18 SVW-PH 06 14 MHS-HP 0F 21 SHS-HP 0F 23 V-POS 1F 50 HD-POS 3F
720P mode
FLEX CONT SPLIT
65 YNRRDC 01 74 CNRRDC 00 89 CNR-0 00 27 FRMBRT 60 11 MVW-PH - - 18 SVW-PH - - 14 MHS-HP - - 21 SHS-HP - - 23 V-POS 1F 50 HD-POS 3F
SPLIT mode
CH U/D, INPUT
FLEX CONT NTSC
65 YNRRDC 01 74 CNRRDC 00 89 CNR-0 00 27 FRMBRT 60 11 MVW-PH 07 18 SVW-PH 07 14 MHS-HP 0F 21 SHS-HP 0F 23 V-POS 1F 50 HD-POS 3F
NTSC/SINGLE/SURF/STROBE mode
SELECT SELECT SELECT SELECT
MENU  
MENU  
MENU   MENU   MENU  
SELECT SELECT
MENU
 
MENU  
FLEX CONT
48 VBLK-T 7F 49 VBLK-B 7F 51 HBLK-R 88 52 HBLK-L 7A 35 FRMTOP 07 36 FRMBTM 07 37 FRMRGT 07 38 FRMLFT 07
CH U/D, INPUT
SELECT
FLEX CONT 1080i PASS
48 VBLK-T 7F 49 VBLK-B 7F 51 HBLK-R 7F 52 HBLK-L 7F 35 FRMTOP 07 36 FRMBTM 07 37 FRMRGT 07 38 FRMLFT 07
1080i pass
MENU
 
FLEX CONT
120 TV/CINE 01 121 T/C DET 07 122 T/C UNL 01 123 T/C LCK 03 126 T/C ARE 05 127 T/C CBR 07 128 T/C YBR 07 129 IPMODE 00 130 C-INT 00
CH U/D, INPUT
MENU
 
MENU
 
1.2 I
2
C Parameter List Cont.
