2
Model: 53SDX20BB 53SDX20B
53FDX20B 43FDX20B
43FDX15B
Cathode-Ray Tube:
53FDX20B R=P16LXL00RFA(U)
53SDX20B G=P16LXL00HHA(U)
53SDX20BB B=P16LXL00BMB(U)
43FDX20B R=P16LXS00RFA
43FDX15B G=P16LXS00HHA
B=P16LXS00BMB
Power Input: 120 volts AC, 60 Hz
Power Consumption:
• Stand-By Power
43FDX20B/43FDX15B . . . . . . . . . . . . .2.7W
53FDX20B/53SDX20B/53SDX20BB . . . .2.7W
• Power Consumption (operating)
43FDX20B/43FDX15B . . . . . . . . . . . . .225W
53FDX20B/53SDX20B/53SDX20BB . . .216W
• Power Consumption (maximum)
43FDX20B/43FDX15B . . . . . . . . . . . . .265W
53FDX20B/53SDX20B/53SDX20BB . . .253W
Antenna Impedance: 75 Ohm Unbalanced
VHF / UHF / CATV
Receiving Channel: BAND
CH
VHF 2~13
UHF 14~69
EXT. Mid (A-5)~(A-1), 4+
CATV Mid. A~I
CATV Super J~W
CATV Hyper (W+1)~(W+28)
Intermediate Frequency: Picture l-F Carrier 45.75 MHz
Sound l-F Carrier 41.25 MHz
Color Sub Carrier 42.17 MHz
Video Output: 1 Volt p-p, 75 ohm
Audio Input: 470 mVrms, 47 k Ohm
Stereo Audio Output: 470 mVrms, 1 k Ohm
Audio Output Power:
Front: 12 watts per channel at 10% distortion,
8 ohm Impedance. Max output – 15 watts.
Anode Voltage:
30.2±0.2kv (1.32±0.2mA)
Brightness: 43” 53”
(white screen) 250cd/m
2
170cd/m
2
Speakers: 2 Woofers - 5 inch (120 mm) round
2 Tweeters - 2 inch (50 mm) round
Dimension:
43” 53”FDX 53”SDX20B 53”SDX20BB
Height (in.) 43
5
/
8
51
5
/
8
55
3
/
4
55
3
/
4
Width (in.) 38
15
/16 46 46 46
Depth (in.) 20
1
/
16
25
1
/
4
25 26
1
/
4
Weight (Ibs.) 148 223 225 200
Circuit Board Assemblies:
C.P.T. (B) P.W.B. Terminal A P.W.B.
C.P.T. (G) P.W.B. Terminal B P.W.B.
C.P.T. (R) P.W.B. VM P.W.B.
Audio Out P.W.B. Surround P.W.B.
2H P.W.B. Power Deflection P.W.B.
Power Supply P.W.B. Control P.W.B.
Signal P.W.B. Control Sub P.W.B.
Convergence P.W.B. Sensor Distribution P.W.B.
CIRCUIT PROTECTION
CAUTION: Below is an EXAMPLE only. See Replacement Parts List for details. The following symbol near the fuse
indicates fast operation fuse (to be replaced). Fuse ratings appear within the symbol.
