Hitachi 53SDX20BB - Replacement Parts List

45
REPLACEMENT PARTS LIST
PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
!
Capacitors: Resistors: Semiconductors:
AL: Aluminum Electrolytic CF: Carbon Film TR: Transistor
CD: Ceramic Disc CC: Carbon Composition DI: Diode
EL: Electrolitic MF: Metal Oxide ZD: Zener Diode
PF: Polyester Film VR: Variable Resistor VA: Varistor
PP: Polypropylene WW: Wire Wound TH: Termistor
PL: Plastic FR: Fuse Resistor IC: Integrated Circuit
TA: Tantalum MG: Metal Grazed
PR: Paper
TM: Trimmer
MC: Mylar
ABBREVIATIONS
SYMBOL PART PART SYMBOL PART PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
CK01 0800335R CAP.-ELECTRO. 220UF-M(SMG) 16V
CAPACITORS CK03 0800326R CAP.-ELECTRO. 100UF-M 16V
CE01 0880044R CAP.-POLYESTER 0.01UF-KEB 50V CK04 0880194R CAP.-POLYESTER 0.1UF-J 50V
CE02 0800321R CAP.-ELECTRO. 47UF-M 50V CK05 0800353R CAP.-ELECTRO.470UF-M 16V
CE03 0880194R CAP.-POLYESTER 0.1UF-J 50V CK06 0880194R CAP.-POLYESTER 0.1UF-J 50V
CE04 0890066R CAP.CERAMIC 27PF-J 50V CK07 0800326R CAP.-ELECTRO. 100UF-M 16V
CE05 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CK08 0880194R CAP.-POLYESTER 0.1UF-J 50V
CE06 0880044R CAP.-POLYESTER 0.01UF-KEB 50V CK09 0880194R CAP.-POLYESTER 0.1UF-J 50V
CE07 0890061R CAP.-CERAMIC 10PF- 50V CK10 0800326R CAP.-ELECTRO. 100UF-M 16V
CE09 0880194R CAP.-POLYESTER 0.1UF-J 50V CK11 0880035R CAP.-POLY 2200PF-50V
CE10 0800321R CAP.-ELECTRO. 47UF-M 50V CK12 0890076R CAP.CERAMIC 150PF-K 50V
CE13 0244541F CAPACITOR-CERAMIC 0.01MF-K B 500V CK15 0880031R CAP.-POLY.1000PF-K 50V
CE14 0244541F CAPACITOR-CERAMIC 0.01MF-K B 500V CK18 0880044R CAP.-POLYESTER 0.01UF-KEB 50V
CE15 0880039R CAP.-POLYESTER 0.0047UF-KEB50V CK19 0880044R CAP.-POLYESTER 0.01UF-KEB 50V
CE16 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CK20 0890076R CAP.CERAMIC 150PF-K 50V
CE24 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CK21 0890076R CAP.CERAMIC 150PF-K 50V
CE25 AL00027R CAP.-ELECTORO. 4.7UF-M 250V CK22 0890083R CAP.-CERAMIC 470PF-K 50V
CE26 AL01166R CAP.ELECTROLYTIC 100UF-M(YXF)50V CK23 0890076R CAP.CERAMIC 150PF-K 50V
CE27 AL01166R CAP.ELECTROLYTIC 100UF-M(YXF)50V CK24 0890076R CAP.CERAMIC 150PF-K 50V
CE28 0800303R CAP.-ELECTRO. 22UF-M 50V CK25 0890076R CAP.CERAMIC 150PF-K 50V
CE29 0800303R CAP.-ELECTRO. 22UF-M 50V CK27 0800356N CAP.-ELECTRO. 470UF-M 50V
CE30 0247848R CAP.-CERAMIC 56PF-J SL 500V CK28 0800356N CAP.-ELECTRO. 470UF-M 50V
CE31 0247848R CAP.-CERAMIC 56PF-J SL 500V CK29 0890076R CAP.CERAMIC 150PF-K 50V
CE32 AL00032R CAP.-ELECTORO. 47UF-M 250V CK30 0890076R CAP.CERAMIC 150PF-K 50V
CE33 0244541F CAPACITOR-CERAMIC 0.01MF-K B 500V CK31 0890076R CAP.CERAMIC 150PF-K 50V
CF01 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CK32 0890076R CAP.CERAMIC 150PF-K 50V
CF02 0255520R CAP.-ELECTRO 0.47UF 250V(KME) CK33 0890076R CAP.CERAMIC 150PF-K 50V
CF03 AN01631F 1000PF1500VMETALLIZ POLYPROPYLENE FILM CAPA CK34 0890076R CAP.CERAMIC 150PF-K 50V
CF04 0880034R CAP.-POLYESTER 0.0018UF-KEB50V CK36 0800355N CAP.ELECTRO. 470UF-M 35V
CF05 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CK37 0800355N CAP.ELECTRO. 470UF-M 35V
CF06 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V CK43 0880044R CAP.-POLYESTER 0.01UF-KEB 50V
CF18 0245158 CAPACITOT CERAMIC 68PF/2KV CK51 0890084R CAP.-CERAMIC 560PF-K 50V
CF19 0245156 CAPACITOT CERAMIC 22PF/2KV CL01 0880053R CAP.-POLYESTER 0.047UF-KEB 50V
Note: The chassis for DP15H/DP15J/DP15K are the same as the chassis for DP15 except the following:
1. Convergence Focus PWB - Please refer to the Parts List below.
2. DCU Parameter - Please refer to this Service Manual.
3. Signal PWB - Add Diode D007 to change OSD - Please refer to the Parts List below.
4. Cabinet - Add 4 more sensor holder for a total of 8 to convert to Magic Focus.
Please refer to Service Manual PA No. 0146 for other information not included in this Service Manual.
