46
PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to sefety. Before replacing
any of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
!
SYMBOL PART PART SYMBOL PART PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
CL02 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DK36 2331815M ZENER HZ7-B2
CL03 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DK37 2331815M ZENER HZ7-B2
CL04 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DK39 CH02021M DIODE 1SS133 T-72
CL05 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DK41 2331815M ZENER HZ7-B2
CL06 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DK42 2331815M ZENER HZ7-B2
CL07 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DL01 2331815M ZENER HZ7-B2
CL08 0880053R CAP.-POLYESTER 0.047UF-KEB 50V DL02 2331815M ZENER HZ7-B2
CL09 0800326R CAP.-ELECTRO. 100UF-M 16V DL03 2331815M ZENER HZ7-B2
CL10 0880194R CAP.-POLYESTER 0.1UF-J 50V DL04 2331815M ZENER HZ7-B2
DIODES DL05 2331815M ZENER HZ7-B2
D007 CH02021M DIODE 1SS133 T-72 DL06 2331815M ZENER HZ7-B2
DE01 2331849M ZENER HZ12C3 (TA) SI 500MW DL07 2331815M ZENER HZ7-B2
DE02 2335042M ZENER HZ-22 (2L TP) SI 200MA 400MW DL08 2331815M ZENER HZ7-B2
DE03 CH02001M DIODE 1SR139-400 DL10 CH02021M DIODE 1SS133 T-72
DE04 CH02001M DIODE 1SR139-400 DL11 CH02021M DIODE 1SS133 T-72
DE05 CH02001M DIODE 1SR139-400 DL12 CH02021M DIODE 1SS133 T-72
DE06 CH02001M DIODE 1SR139-400 DL13 CH02021M DIODE 1SS133 T-72
DE17 CH02021M DIODE 1SS133 T-72 DL14 CH02021M DIODE 1SS133 T-72
DE18 CH02021M DIODE 1SS133 T-72 DL15 CH02021M DIODE 1SS133 T-72
DF01 CH02021M DIODE 1SS133 T-72 DL16 CH02021M DIODE 1SS133 T-72
DF02 CH02021M DIODE 1SS133 T-72 DL17 CH02021M DIODE 1SS133 T-72
DF03 CH02021M DIODE 1SS133 T-72 DL20 2331815M ZENER HZ7-B2
DF04 2338531M DIODE EG-01C (V) SI 0.5A DL21 2331815M ZENER HZ7-B2
DK01 CH02301M DIODE D2S4M (2A-40V) DL22 2331815M ZENER HZ7-B2
DK04 CH02011M DIODE 1SR153-400 DL23 2331815M ZENER HZ7-B2
DK05 CH02011M DIODE 1SR153-400 DL24 2331815M ZENER HZ7-B2
DK16 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX DL25 2331815M ZENER HZ7-B2
DK16 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX DL26 2331815M ZENER HZ7-B2
DK17 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX DL27 2331815M ZENER HZ7-B2
DK17 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX DL28 2331824M ZENER HZ9B1 TA
DK18 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX DL30 2331824M ZENER HZ9B1 TA
DK18 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX DL31 2331824M ZENER HZ9B1 TA
DK19 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX DL32 2331824M ZENER HZ9B1 TA
DK19 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX DL33 2331824M ZENER HZ9B1 TA
DK20 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX DL34 2331824M ZENER HZ9B1 TA
DK20 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX DL35 2331824M ZENER HZ9B1 TA
DK21 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX DL36 2331824M ZENER HZ9B1 TA
DK21 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX DL37 2331824M ZENER HZ9B1 TA
DK22 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX IC's
DK22 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX IK01 CP07611 ANALOG MONOLITHIC IC (NJM7805FA
DK23 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX IK02 CP01631R ICL-PST9142
DK23 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX IK04 CZ00431 HYBRID IC (STK392-110) 53SDX/FDX
DK24 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX IK04 CZ00432 HYBRID IC (STK392-120) 43FDX
DK24 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX IK05 CZ00431 HYBRID IC (STK392-110) 53SDX/FDX
DK25 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX IK05 CZ00432 HYBRID IC (STK392-120) 43FDX
DK25 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX COILS
DK26 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX LE01 2125811F FILT.COIL(LHL08 100UH)
DK26 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX LE02 2125811F FILT.COIL(LHL08 100UH)
DK27 2334324M Z.D. RD36E TAPE (B3) SI 500MW 36V 53SDX/FDX LE03 BH01341M COIL FERRITE BEADS 0.8UH
DK27 2334334M ZENER RD39E (B3 T2 TP TA) 43FDX/53SDX LK07 BH01341M COIL FERRITE BEADS 0.8UH
DK30 2331815M ZENER HZ7-B2 LK08 BH01341M COIL FERRITE BEADS 0.8UH
DK31 2331815M ZENER HZ7-B2 LK09 BH01342M COIL FERRITE BEADS 2.3UH
DK32 2331815M ZENER HZ7-B2 LK10 BH01342M COIL FERRITE BEADS 2.3UH
DK33 2331815M ZENER HZ7-B2 LK11 BH01342M COIL FERRITE BEADS 2.3UH
DK34 2331815M ZENER HZ7-B2 LK13 BH01342M COIL FERRITE BEADS 2.3UH
DK35 2331815M ZENER HZ7-B2 LK14 2125808N FILT.COIL(LHL08 68UH)
