PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to sefety. Before replacing
any of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
!
SYMBOL PART PART SYMBOL PART PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
LL01 2125811F FILT.COIL(LHL08 100UH) RE20 0700024M RES.-CARBON FLM 1/16W 56-J
TRANSISTORS RE21 AT03857M 100OHM 1/2W RDS50 CARBON FILM RESISTOR
QE01 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE23 AT03869M 820OHM 1/2W RDS50 CARBON FILM RESISTOR
QE02 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE24 0700027M RES.-CARBON FLM 1/16W 100-JB
QE03 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE27 0113750M RES.-CARBON FLM 1/2W 1K-JB
QE04 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE28 0700017M RES.-CARBON FLM 1/16W 18-J
QE05 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE29 0113750M RES.-CARBON FLM 1/2W 1K-JB
QE07 CF01881R TRS. 2SA1283 E RE31 0700014M RES.-CARBON FLM 1/16W 10-J
QE08 CF01871R TRS. 2SC3243 E RE32 0700014M RES.-CARBON FLM 1/16W 10-J
QE10 CF01871R TRS. 2SC3243 E RE33 AT03848M 22.0OHM 1/2W RDS50 CARBON FILM RESISTOR
QE11 CF01881R TRS. 2SA1283 E RE50 AT03419S METAL OX. 470 OHM 2W
QE22 2326821R TRANSISTOR 2SA1371 (E/F) RE51 0700041M RES.-CARBON FLM 1/16W 1.0K-JB
QE23 2315381 TRS. 2SA1837 RE52 0100021M RES.-CARBON FLM 1/8W 15-JB
QE24 2315381 TRS. 2SA1837 RE55 0700067M RES.-CARBON FLM 1/16W 100K-JB
QE25 2315391 TRS. 2SC4793 RE56 0100065M RES.-CARBON FLM 1/8W 1K-JB
QE26 2315391 TRS. 2SC4793 RE57 0113791M RES.-CARBON FLM 1/2W 47K-JB
QE35 2326811R TRANSISTOR 2SC3468 (E/F) RE60 AT03897M 100KOHM 1/2W RDS50 CARBON FILM RESISTOR
QE36 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE61 0100065M RES.-CARBON FLM 1/8W 1K-JB
QF03 2320663M TRS. 2SC1213A (C) RE62 0100033M RES.-CARBON FLM 1/8W 47-JB
QF04 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW RE66 0100033M RES.-CARBON FLM 1/8W 47-JB
QF05 2320663M TRS. 2SC1213A (C) RE67 AT03853M 47.0OHM 1/2W RDS50 CARBON FILM RESISTOR
QF06 CF00821F TRS. 2SC4686A 1200V RE68 AT03853M 47.0OHM 1/2W RDS50 CARBON FILM RESISTOR
QF07 CF00821F TRS. 2SC4686A 1200V RE69 0113698M RES.-CARBON FLM 1/2W 8.2-J
QF08 CF00821F TRS. 2SC4686A 1200V RE70 0113698M RES.-CARBON FLM 1/2W 8.2-J
QK01 2312171 TRS. 2SC3852 RE71 0100041M RES.-CARBON FLM 1/8W 100-JB
QK02 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW RE72 0100041M RES.-CARBON FLM 1/8W 100-JB
QK03 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW RE73 0100095M RES.-CARBON FLM 1/8W 18K-JB
QK06 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE74 AT03894M 56KOHM 1/2W RDS50 CARBON FILM RESISTOR
QK07 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE75 AT03894M 56KOHM 1/2W RDS50 CARBON FILM RESISTOR
QK08 2320591M TRS. 2SC458 (B TZ/C TZ) SI 230MHZ200MW RE76 0100095M RES.-CARBON FLM 1/8W 18K-JB
QL10 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW RE77 AT03571S METAL OX. 220OHM 3W
QL11 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW RE78 AT03571S METAL OX. 220OHM 3W
QL12 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW REE5 AT03897M 100KOHM 1/2W RDS50 CARBON FILM RESISTOR
QL13 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW REE6 0700065M RES.-CARBON FLM 1/16W 68K-JB
QL14 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW REE7 0700064M RES.-CARBON FLM 1/16W 56K-JB
QL15 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW REF0 0100113M RES.-CARBON FLM 1/8W 100K-JB
QL16 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW REF1 0700055M RES.-CARBON FLM 1/16W 12K-JB
QL17 2320637M TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW REF4 0700047M RES.-CARBON FLM 1/16W 3.3K-JB
RESISTORS RF07 0700067M RES.-CARBON FLM 1/16W 100K-JB
RE01 0100065M RES.-CARBON FLM 1/8W 1K-JB RF08 0700054M RES.-CARBON FLM 1/16W 10K-JB
RE02 0700055M RES.-CARBON FLM 1/16W 12K-JB RF09 0700054M RES.-CARBON FLM 1/16W 10K-JB
RE03 0700066M RES.-CARBON FLM 1/16W 82K-JB RF10 AT03857M 100OHM 1/2W RDS50 CARBON FILM RESISTOR
RE04 0700024M RES.-CARBON FLM 1/16W 56-J RF11 0700041M RES.-CARBON FLM 1/16W 1.0K-JB
RE05 AT03866M 470OHM 1/2W RDS50 CARBON FILM RESISTOR RF13 0700056M RES.-CARBON FLM 1/16W 15K-JB
RE06 0700018M RES.-CARBON FLM 1/16W 22-J RF14 0700025M RES.-CARBON FLM 1/16W 68-J
RE07 0700054M RES.-CARBON FLM 1/16W 10K-JB RF15 AT03654M RES.MTL GRAZD FLM 1/2W 180K
RE08 0700054M RES.-CARBON FLM 1/16W 10K-JB RF16 AT03654M RES.MTL GRAZD FLM 1/2W 180K
RE09 0700055M RES.-CARBON FLM 1/16W 12K-JB RF17 AT03654M RES.MTL GRAZD FLM 1/2W 180K
RE10 0700055M RES.-CARBON FLM 1/16W 12K-JB RF18 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE11 0700027M RES.-CARBON FLM 1/16W 100-JB RF19 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE12 0700024M RES.-CARBON FLM 1/16W 56-J RF20 0700025M RES.-CARBON FLM 1/16W 68-J
RE13 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RF21 0700049M RES.-CARBON FLM 1/16W 4.7K-JB
RE16 0700027M RES.-CARBON FLM 1/16W 100-JB RF22 0187096M RES.-CARBON FLM 1/16W 20K-JB
RE17 AT03876M 2.7OHM 1/2W RDS50 CARBON FILM RESISTOR RF23 0700063M RES.-CARBON FLM 1/16W 47K-JB
RE18 0700065M RES.-CARBON FLM 1/16W 68K-JB RF25 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE19 0700052M RES.-CARBON FLM 1/16W 6.8K-JB RF26 AT03662M RES.MTL GRAZD FLM 1/2W 560K
