PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to sefety. Before replacing
any of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
!
SYMBOL PART PART SYMBOL PART PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
RF27 AT03661M RES.MTL GRAZD FLM 1/2W 470K RK54
RF28 0700059M RES.-CARBON FLM 1/16W 27K-JB RK54
RF29 0700049M RES.-CARBON FLM 1/16W 4.7K-JB RK55 AT03406S METAL OX. 150OHM 2W
RF30 AT03892M 39KOHM 1/2W RDS50 CARBON FILM RESISTOR RK56 0700047M RES.-CARBON FLM 1/16W 3.3K-JB
RF33 AT03892M 39KOHM 1/2W RDS50 CARBON FILM RESISTOR RK58
RF34 0700045M RES.-CARBON FLM 1/16W 2.2K-JB RK59 AT03411S METAL OX. 220OHM 2W
RF35 AT03911M 1MOHM 1/2W RDS50 CARBON FILM RESISTOR RK60 0700047M RES.-CARBON FLM 1/16W 3.3K-JB
RF36 AT03857M 100OHM 1/2W RDS50 CARBON FILM RESISTOR RK62
RF37 AT03911M 1MOHM 1/2W RDS50 CARBON FILM RESISTOR RK62
RK01 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK63 AT03406S METAL OX. 150OHM 2W
RK02 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK64 0700054M RES.-CARBON FLM 1/16W 10K-JB
RK03 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK65 0700054M RES.-CARBON FLM 1/16W 10K-JB
RK04 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK90 0700054M RES.-CARBON FLM 1/16W 10K-JB
RK05 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK92 0700041M RES.-CARBON FLM 1/16W 1.0K-JB
RK06 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK97 AT03193S METAL OX. 1.5OHM 1W
RK07 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RK99 0188097M RES.-CARBON FLM 1/2W 3.3-J
RK08 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RL10 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK09 0100057M RES.-CARBON FLM 1/8W 470-JB RL11 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK10 0700042M RES.-CARBON FLM 1/16W 1.2K-JB RL12 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK11 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL13 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK12 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL14 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK13 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL15 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK17 0700046M RES.-CARBON FLM 1/16W 2.7K-JB RL16 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK18 0700048M RES.-CARBON FLM 1/16W 3.9K-JB RL17 0100129M RES.-CARBON FLM 1/8W 470K-JB
RK22 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL20 0100129M RES.-CARBON FLM 1/8W 470K-JB 43FDX
RK23 0100085M RES.-CARBON FLM 1/8W 6.8K-JB RL20 0100133M RES.-CARBON FLM 1/8W 680K-JB SDX
RK24 0700043M RES.-CARBON FLM 1/16W 1.5K-JB RL21 0100117M RES.-CARBON FLM 1/8W 150K-JB 43FDX
RK25 0700063M RES.-CARBON FLM 1/16W 47K-JB RL21 0100119M RES.-CARBON FLM 1/8W 180K-JB 53SDX/FDX
RK26 0700063M RES.-CARBON FLM 1/16W 47K-JB RL22 0100131M RES.-CARBON FLM 1/8W 560K-JB 43FDX
RK27 0700054M RES.-CARBON FLM 1/16W 10K-JB RL22 0100133M RES.-CARBON FLM 1/8W 680K-JB 53SDX/FDX
RK28 0700027M RES.-CARBON FLM 1/16W 100-JB RL23 0100123M RES.-CARBON FLM 1/8W 270K-JB
RK29 0700027M RES.-CARBON FLM 1/16W 100-JB RL23 0100125M RES.-CARBON FLM 1/8W 330K-JB 53FDX
RK30 0700027M RES.-CARBON FLM 1/16W 100-JB RL24 0100131M RES.-CARBON FLM 1/8W 560K-JB 43FDX
RK31 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL24 0100133M RES.-CARBON FLM 1/8W 680K-JB 53SDX/FDX
RK32 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL25 0100117M RES.-CARBON FLM 1/8W 150K-JB 43FDX
RK33 0700041M RES.-CARBON FLM 1/16W 1.0K-JB RL25 0100119M RES.-CARBON FLM 1/8W 180K-JB 53SDX/FDX
RK34 0700063M RES.-CARBON FLM 1/16W 47K-JB RL26 0100131M RES.-CARBON FLM 1/8W 560K-JB 43FDX
RK35 0700063M RES.-CARBON FLM 1/16W 47K-JB RL26 0100133M RES.-CARBON FLM 1/8W 680K-JB 53SDX/FDX
RK36 0700063M RES.-CARBON FLM 1/16W 47K-JB RL27 0100123M RES.-CARBON FLM 1/8W 270K-JB
RK37 0700063M RES.-CARBON FLM 1/16W 47K-JB RL27 0100125M RES.-CARBON FLM 1/8W 330K-JB 53FDX
RK38 0700063M RES.-CARBON FLM 1/16W 47K-JB RL30 0700027M RES.-CARBON FLM 1/16W 100-JB
RK39 0700063M RES.-CARBON FLM 1/16W 47K-JB RL31 0700027M RES.-CARBON FLM 1/16W 100-JB
RK40 0700047M RES.-CARBON FLM 1/16W 3.3K-JB RL32 0700027M RES.-CARBON FLM 1/16W 100-JB
RK42 RL33 0700027M RES.-CARBON FLM 1/16W 100-JB
RK42 RL34 0700027M RES.-CARBON FLM 1/16W 100-JB
RK43 AT03411S METAL OX. 220OHM 2W RL35 0700027M RES.-CARBON FLM 1/16W 100-JB
RK44 0700047M RES.-CARBON FLM 1/16W 3.3K-JB RL36 0700027M RES.-CARBON FLM 1/16W 100-JB
RK46 RL37 0700027M RES.-CARBON FLM 1/16W 100-JB
RK46 Cabinet Parts
RK47 AT03406S METAL OX. 150OHM 2W Symbol Part No. Part Description
RK48 0700047M RES.-CARBON FLM 1/16W 3.3K-JB N203B KQ00431K Blue Lens Assy 53SDX20BB
RK50 N203G KQ00434K Green Lens Assy 53SDX20BB
RK50 N203R KQ00435K Red Lens Assy 53SDX20BB
RK51 AT03411S METAL OX. 220OHM 2W N200 KQ00811 Lens Assy (RGB) 43FDX15 20B
RK52 0700047M RES.-CARBON FLM 1/16W 3.3K-JB N200 KQ00811 Lens Assy (RGB) 53FDX20B
RK54 N203B KQ02221K Blue Lens Assy 53SDX20B
