PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to sefety. Before replacing
any of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
!
SYMBOL PART PART SYMBOL PART PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
N203G KQ02222K Green Lens Assy 53SDX20B
N203R KQ02223K Red Lens Assy 53SDX20B
# KR01162 Screen Assy 53SDX20BB
# KR02531 Screen Assy 43FDX20B
# KR02532 Screen Assy 53FDX20B
# KR02533 Screen Assy 53SDX20B
# KR02534 Screen Assy 43FDX15B
#20 KS02024 43" First Surface Mirror
#83 KS02028 53" First Surface Mirror
#260 NJ01471 Sensor Holder Assy 53"
#550 NJ05481 Catch Sensor Holder Assy 43"
# NT02273 Screen Frame Assy 53FDX20B
# NT02283 Screen Frame Assy 43FDX15B
# NT02283 Screen Frame Assy 43FDX20B
# NT02313 Screen Frame Assy 53SDX20B
# NT02314 Screen Frame Assy 53SDX20BB
#299 PH07002 53" Bottom Rail
#451 PH08305 43" Speaker Grill
#415 PH08913 53" Speaker Grill
#10 QD08992 43" Back Cover
#165 QJ00673 43" Foot ( x 4)
# Red PRT Assy 53SDX20BB
# Green PRT Assy 53SDX20BB
# Blue PRT Assy 53SDX20BB
# UE08744 Red PRT Assy 53SDX20B
# UE08745 Green PRT Assy 53SDX20B
# UE08756 Blue PRT Assy 53SDX20B
# UE20234 Red PRT Assy 53FDX20B
# UE20235 Green PRT Assy 53FDX20B
# UE20236 Blue PRT Assy 53FDX20B
# UE20311 Red PRT Assy 43FDX15 20B
# UE20312 Green PRT Assy 43FDX15 20B
# UE20313 Blue PRT Assy 43FDX15 20B
Miscellaneous
PS3 2959055 6P Connector
# BY01552 43" Yoke Assy (R, G, B)
# BY01661 53" Yoke Assy (R, G, B)
GF01 CJ00072R Spark Gap 2.5 KV
UKDG CS00452 DCU Assy
PDK1 ED01491U 7P Plug Pin
PDK4 ED01491U 7P Plug Pin
PDK3 ED01492U Connector
PDKP ED01492U Connector
PDC ED03205 9P 2.5 mm Connector
PDS ED03205 9P 2.5 mm Connector
PDG ED03212 15P 2.5 mm Connector
SK01 FE10332R DCAM Switch
Accessories
Part No. Description
# H312251 43" Full Mode Screen Jig
# H312252 43" V Squeeze Screen Jig
# H312253 53" Full Model Screen Jig
# H312254 53" V Squeeze Screen Jig
E301 HL01832 CLU4322UG Remote Control
N201 QR52481 Owners' guide
