INSTALLATION & MAINTENANCE MANUAL
7.1.2.9 Turn on All Zones
This function is to turn on all the activated zones at the same time.
Step1. Select "Turn on All Zones" and press "OK".
Step1. Press "
" or " " to select to select "Yes" or "No", and
press "OK" to return to Zone Installation Menu.
7.1.2.10 Check for Zoning Kit
This function is to display various statuses of the air conditioner.
Step1. Select "Check Menu" on "Service & Installation Menu"
and press "OK".
Step2. Select check item in table below and press "OK".
Step3. Select "Zoning Kit" and press "OK".
Item Function
Check 1 (zoning kit) Sensor condition of zoning kit are monitored and displayed.
Alarm History Display (zoning kit)
Previous alarm history data of zoning kit is displayed (Max 30).
The alarm history can be deleted.
Check PCB of the Units (zoning kit) The result and diagnosis of ZIB's PCB check is displayed.
Zone Installation Menu
Damper Timing
Minimum Airflow Ratio
Airflow
BackOK Select
Turn On All Zones
Turn On All the Zones?
Back
OK Confirm
Yes
No
Service & Installation
Check Menu
Zone Installation Menu
Installation Menu
Service Menu
OK
Select Back
(Mon) 16:30
