8. PRECAUTIONS ON OPERATION
8-1. Unpacking
The parts illustrated in Fig. 6 are packaged together with.
When unpacking, carefully confirm that all parts are accounted for.
1. Miter Gauge (1 piece)
2. Saw Blade Guard and Spreader Assembly
(1 piece) (for USA, AUS and NZL)
3. Extension Supporter (4 pieces)
4. Extension Wing (2 pieces)
5. Elbow (1 piece)
6. Fence Ass'y (1 piece)
7. Hex. Wrench (23 mm x 26 mm) (1 piece)
8. Wrench (22 mm) (1 piece)
9. Handle (1 piece)
10. Clamp Handle (A) (1 piece)
11. 6 x 20 mm Bolt (with/washers) (6 pieces)
12. 6 x 35 mm Bolt (1 piece)
13. 6 x 60 mm Bolt (1 piece)
14. 6 mm Spring Washer (2 pieces)
15. 6 mm Flat Washer (2 pieces)
16. 8 x 20 mm Bolt (with/washers) (12 pieces)
17. Set Plate (4 pieces)
18. Scale (2 pieces) (for USA, AUS and NZL)
19. Saw Blade Guard and Splitter (1 piece)
20. 6 x 16 mm Bolt (1 piece)
21. 6 mm Spring Washer (1 piece)
22. Flat Washer (1 piece)
23. Spacer (2 pieces)
24. 6 x 35 mm Special Bolt (1 piece)
25. 6 mm Flat Washer (1 piece)
26. 6 mm Wing Nut (1 piece)
27. Hex. Wrench (1 piece)
28. Push Stick (1 piece)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2021
22
23
24
25
26
27
28
Fig. 6
