6-16 Utility
Discovery tree
・Displays the detected host, adapter, adapter port, virtual port, fabric, target, and LUN as icons.
・Local host ・Adapter
・Adapter port ・Target
・LUN ・Fabric
Property tab
・When you select an icon of the discovery tree, a property tab corresponding to the icon is displayed.
On the tab page you can view the icon information and parameters or change parameters.
[Discovery Information] tab
Target icons: Host, fabric, virtual port
Item: Displays the summary of the detected element.
To Next Page
