6-20 Utility
Updating Firmware/Bootcode
・Windows Server 2012 / Windows Server 2012 R2 Environment
The following is firmware/bootcode update procedure by OneCommandManager version 6.1.14.1-1
1. Select [Batch] on the menu bar and then select [Download Firmware…].
2. The " Firmware File Selection " dialog box appears. Select a firmware or bootcode file and then click [Open].
3. The tree appears in the screen as shown below. Select/unselect the checkbox corresponding to the adapter or adapter port to
select the target to be updated.
4. Click [Start Download] to start updating.
5. Check that the process bar indicates "100%" and "Failed Downloads: 0" is indicated. Then click [Close] to exit.
