Ports (12~21)
(1) COMPUTER IN port
(2) HDBaseT port *
(3) LAN port
(4) WIRELESS port
(5) HDMI 1 / MHL port
(6) HDMI 2 port
(7) HDMI OUT port
(8) VIDEO port
(9) AUDIO IN1 port
(10) AUDIO IN2 (L, R) ports
(11) AUDIO OUT port
(12) MONITOR OUT port
(13) REMOTE CONTROL IN port
(14) REMOTE CONTROL OUT port
(15) CONTROL port
* CP-WU5505/CP-WX5505/CP-X5555 only
Introduction
Part names (continued)
CP-WU5505/CP-WX5505/CP-X5555
CP-WU5500/CP-WX5500/CP-X5550
(2)
(3)
(10)
(8) (9) (15) (13) (14)
(7) (5) (6) (12) (4)
(11)
(1)
(3)
(10)
(8) (9) (15) (13) (14)
(7) (5) (6) (12) (4)
(11)
(1)
