Hitachi CP-WX11000 Service Manual

2
CP-WX11000 ( P6WX )
1. Features
• High Brightness • Remote Control Via Your Web Browser
• Low Noise • Rich Connectivity
2. Specifications
Liquid
crystal
panel
Drive system TFT active matrix
Panel size 3.1cm (1.22 type)
Number of pixels 1366 (H) x 800 (V)
Lamp 350W UHB
Digital
signal
HDMI
Type:T.M.D.S
Signal level : DC : 3.3V±5%
AC : 0.15-1.56Vp-p
DVI-D
Type : T.M.D.S
Amplitude deifferential signal: DC:150-1200mV AC:1.56Vp-p
Computer
signal
Computer IN
D-sub 15pin
Video : Analog 0.7Vp-p(75 termination)
H/V. sync. : TTL level (positive/negative)
Composite sync. : TTL level
BNC
Monitor OUT
Video:Analog 0.7Vp-p, 75 output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
VIDEO
signal
VIDEO IN 1.0Vp-p (75 termination)
S-VIDEO IN
Y signal: 1.0±0.1Vp-p, (75 termination)
C signal: 0.286±0.1Vp-p (NTSC burst signal, 75 termination)
0.3±0.1Vp-p (PAL/SECAM burst signal, 75 termination)
COMPONENT
VIDEO
Y 1.0±0.1Vp-p, 75 termination (positive)
C
B
/P
B
0.7±0.1Vp-p, 75 termination (positive)
C
R
/P
R
0.7±0.1Vp-p, 75 termination (positive)
RS232C
INPUT Hi: Max. 20V, Min. 2.6V Lo: Typ. –20.0V, Max. 0.8V
OUTPUT Hi: Typ. 8.0V, Min. 5.0V Lo: Typ. –7.0V, Max. –5.0V
NETWORK 100Base-TX/10Base-T Differential output: 1.9~2.1V (100 termination)
Power supply AC110~120V/6.0A, AC220~240V/3.1A
Power consumption 540W
Dimensions 476 (W) x 272 (H) x 469 (D) mm (Not including protruding parts)
Weight 13.1kg ( Not including projection lens )
Temperature range
Operation : 5~35°C
Storage : -20~60°C
Accessories
Remote control x1
RGB cable x 1
Power cords x 3
Batteries x 2
User’s manuals x 1
LENS adapter x 1
Hexagon wrench x 1
