Hitachi CP-X608 Operating Guide

63
Maintenance
1.
Turn the projector off, and unplug the power cord. Allow the
SURMHFWRUWRFRROVXI¿FLHQWO\
2.
After making sure that the projector has cooled adequately,
slowly turn over the projector, so that the bottom is facing.
3.
Remove the battery cover.
Turn the battery cover in the direction indicated “OPEN”
using such as coins. Then the battery cover will come up. While
removing the battery cover, pick its knob.
4.
Take the old battery out.
Press the metal claw of the battery holder. Then the battery
will come up. Remove the battery.
5.
Put a new battery in.
Replace battery with HITACHI MAXELL, Part No.CR2032
RQO\8VHRIDQRWKHUEDWWHU\PD\SUHVHQWDULVNRI¿UHRU
explosion.
Insert a new battery in the battery holder according to its minus terminal
as indicated in the battery holder, so that the side marked by + is
IDFLQJ$QGSXVKWKHEDWWHU\LQWRWKHEDWWHU\KROGHUIXOO\WR¿[
6.
Close the battery cover.
Replace the battery cover in place, then turn it in the
GLUHFWLRQLQGLFDWHG³&/26(´XVLQJVXFKDVFRLQVWR¿[
%.15'
Battery Cover
12'0
Knob
Metal claw
“+” marking
WARNING Ź Always handle the batteries with care and use them only as directed. Battery
PD\H[SORGHLIPLVWUHDWHG'RQRWUHFKDUJHGLVDVVHPEOHRUGLVSRVHRILQ¿UH
$QGDOVRLPSURSHUXVHPD\UHVXOWLQFUDFNLQJRUOHDNDJHZKLFKFRXOGUHVXOWLQ¿UHLQMXU\DQGRU
pollution of the surrounding environment.
• %HVXUHWRXVHRQO\WKHEDWWHULHVVSHFL¿HG'RQRWXVHEDWWHULHVRIGLIIHUHQWW\SHVDWWKHVDPH
time. Do not mix a new battery with used one.
• Make sure the plus and minus terminals are correctly aligned when loading a battery.
If the battery is placed in the battery holder upside-down, it may be hard to remove.
• Keep a battery away from children and pets. If swallowed consult a physician immediately for emergency treatment.
• Do not short circuit or solder a battery.
• 'RQRWDOORZDEDWWHU\LQD¿UHRUZDWHU.HHSEDWWHULHVLQDGDUNFRRODQGGU\SODFH
• ,I\RXREVHUYHDOHDNDJHRIDEDWWHU\ZLSHRXWWKHÀRZHUDQGWKHQUHSODFHDEDWWHU\,IWKHOLTXLG
adheres to your body or clothes, rinse well with water immediately.
• Obey the local laws on disposing the battery.
Internal clock battery
Consumption of the battery makes the clock not to work correctly. When the clock is wrong or it has
stopped, please replace the battery according to the following procedures.
NOTE • If the battery is placed in the battery holder upside-down, follow the procedure below
to remove and reload it properly.
1. Remove the battery cover as described in steps 1 through 3 above.
2. Turn the projector over again, so that the top of the projector is facing up.
3. While lifting the side of the projector closest to the lens, press the metal claw of the battery
holder. The battery will fall out of the holder, so be careful not to lose it.
4. Turn the projector over once more, so that the bottom faces up, and reload the battery correctly.
• The internal clock’s time will be reset when the battery is removed.
3OHDVHUHFRQ¿JXUHWKHWLPHYLDWKHPHQXRUDZHEEURZVHUDIWHUUHSODFLQJWKHEDWWHU\
(

2.5.7 Date/Time Settings of the User’s Manual - Network Functions)

Hitachi CP-X608 Specifications

General

Resolution	XGA (1024 x 768)
Contrast Ratio	500:1
Lamp Life	2000 hours (normal mode), 3000 hours (eco mode)
Display Type	LCD
Throw Ratio	1.5 - 1.8:1
Screen Size	30 - 300 inches
Zoom Ratio	1.2x
Brightness	4000 ANSI Lumens
Input Ports	S-Video, Composite Video
Audio Output	1W Mono
Lamp Type	UHB
Output Connectors	D-sub 15 pin x 1
Noise Level	35 dB (normal mode)
Power Consumption	310W (Normal mode), 250W (Eco mode)
