SPECIFICATIONS
Model D10VF D10VG D13VF D13VG
Voltage (by areas)* (110V, 220V, 230V, 240V)
Power input 710W*
No load speed 0–3,000min
–1
0–1,200min
–1
0–850min
–1
0–600min
–1
Drill chuck capacity 10 mm 13 mm
Steel
Twist Bit 10 mm 10 mm 13 mm 13 mm
Hole Saw – 38 mm 51 mm 70 mm
Capacity Flat Spade Bit 25 mm 32 mm 40 mm 40 mm
Wood Auger Bit – – 32 mm 38 mm
Hole Saw 29 mm 70 mm 102 mm 114 mm
Weight (without cord)
Spec. for keyed chuck 1.8 kg 1.9 kg 2.1 kg 2.1 kg
Spec. for keyless chuck 1.8 kg 1.9 kg 2.0 kg 2.0 kg
*Be sure to check the nameplate on product as it is subject to change by areas.
<Capacity with Angle attachment (Optional accessory for D13VF and D13VG)>
Model D13VF D13VG
Speed of angle unit LOW(650min
–1
) HIGH(1350min
–1
) LOW(400min
–1
) HIGH(900min
–1
)
Steel
Twist Bit 13 mm 13 mm 13 mm 13 mm
Hole Saw 64 mm 32 mm 70 mm 51 mm
Capacity Flat Spade Bit 40 mm 32 mm 40 mm 40 mm
Wood Auger Bit 38 mm 29 mm 38 mm 32 mm
Hole Saw 114 mm 64 mm 114 mm 102 mm
STANDARD ACCESSORIES
<D10VF>
(1) Chuck wrench (Spec. only for keyed chuck) ...... 1
<D10VG and D13VF>
(1) Side handle ................................................................ 1
(2)Chuck wrench (Spec. only for keyed chuck) ........ 1
<D13VG>
(1) Side handle ................................................................ 1
(2) Handle joint ................................................................ 1
(3) Chuck wrench (Spec. only for keyed chuck) ...... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
<D10VF>
(1) Side handle
(2) Hook (A)
<D10VG>
(1) Hook (A)
<D13VF and D13VG>
(1) Hook (A)
(2) Angle attachment
Optional accessories are subject to change without notice.
APPLICATIONS
䡬 Boring holes in metal, wood and plastic.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, inviting serious
accident.
3. Extension cord
When the work area is removed from the power
source. Use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Selecting the appropriate drill bit:
䡬 When boring metal or plastic
Use ordinary metalworking drill bits.
䡬 When boring wood
Use ordinary woodworking drill bits.
However, when drilling 6.5 mm or smaller holes,
use a metalworking drill bit.
5. Mounting and dismounting of the bit
For keyed chuck (Fig. 1)
(1) Open the chuck jaws, and insert the bit into the
chuck.
(2) Place the chuck wrench in each of the three holes
in the chuck, and turn it in the clockwise direction
(viewed from the front side). Tighten securely.
