3-2
No
Ye s
Check D1008, L1012, C1007, C2015 and
their periphery, and service it if defective.
FLOW CHART NO.9
EV+3.3V is not outputted.
Is 4V voltage supplied to Pin(1) of IC1003?
Replace IC1003.
Is the "L" pulse (approximately 0V) inputted to
the base of Q053?
Is the "H" pulse (approximately 5V) inputted to
the base of Q054?
Is 5V voltage supplied to the
Pin(37,99) of IC501.
Replace Q053. Replace Q054.
Ye s
No
Is 2.8V voltage supplied to Pin(1) of IC1002?
FLOW CHART NO.10
EV 1.2V is not outputted.
Replace IC1002.
Check D1030, L1009, C1035, C1107, and their
periphery, and service it if defective.
FLOW CHART NO.8
P-ON+5V (AL+5V) is not outputted. (P-ON+44V is outputted normally)
Is 5V voltage supplied to the collector of Q056?
Replace Q056.
No
No
Ye s
Ye s
Is the "H" pulse inputted to the base of Q056?
Check D016, L013, C017, C018, and their
periphery, and service it if defective.
Check R058, R059, R060 and their periphery,
and service it if defective.
FLOW CHART NO.7
AL+9V (AL+12V) is not outputted. (P-ON+44V is outputted normally)
Is 12V voltage supplied to the collector of Q055?
Replace Q055.
No
Ye s
Ye s
Check D014, D017, L010, C015, and their
periphery, and service it if defective.
FLOW CHART NO.6
P-ON+44V is not outputted.
Is 44V voltage supplied to the emitter of Q053?
No
No
Is the "H" pulse (approximately 10V) inputted to
the base of Q055?
Check D054, R055, and their periphery,
and service it if defective.
No
Ye s
Ye s
Replace IC501.
Ye s
Check AL+5V and
Timer+5V line, and
service it if defective.
No
No
Check D013, C013, and their periphery, and
service it if defective.
Ye s
To Next Page
