Hitachi DV-PF7E - General Information; Specifications

2-1
2-1 SPECIFICATIONS
ITEM DESCRIPTION
Video section
TV system PAL
Video head Rotating 4 heads
Recording system
Rotating 2 head helical scan brightness signal FM method
VHS standard for methods to directly record color signal low frequency conversions
Audio track
Hi-Fi audio track: 2 channel
Normal audio track: 1 channel
Tape VHS-type videocassette
Tape speed {SP}: 23.39 mm/s {LP}: 11.70 mm/s
Maximum record and
playback time
{SP}: 4 hours (with E-240 used)
{LP}: 8 hours (with E-240 used)
Receiving channel
DV-PF7E/PF6E DV-PF7E(UK)
CH Indication TV Channel CH Indication TV Channel
02-12 E2-E12 01-10 TRA-IRJ, GAP
13-20 A-H (only ITALY) 21-69 E21-E69
21-69 E21-E69 74-78 X.Y.Z.Z+1.Z+2
74-78 X.Y.Z.Z+1.Z+2 88-99, 100 S1-S20, GAP
80-99, 100 S1-S20, GAP 121-141 S21-S41
Reception system Up-heterodyne
RF converter RF CONVERTER
Converter output UHF 22 - 69 ch, I: 35 ch
Timer display 24-hour system
Video output impedance 75 Ω
Video output level 1.0 V P-P
Audio output level -6 dB 1 kΩ unbalance (high impedance)
Video input level 0.5-2.0 V P-P
Audio input level -10 dBV
Video S/N ratio 40 dB or more
Audio S/N ratio 36 dB or more
Hi-Fi audio
Frequency characteristic: 20-20,000 Hz
Dynamic range: 70 dB or more
DVD section
Disc used DVD video disc, Music CD disc
Audio frequency
characteristic
DVD (linear audio)
20 Hz - 22 kHz (48 kHz sampling frequency)
20 Hz - 44 kHz (96 kHz sampling frequency)
Music CD
20 Hz - 20 kHz (JEITA)
Signal/Noise (S/N) ratio CD: 70 dB (JEITA)
Dynamic range DVD (linear audio): 70 dB, CD: 70 dB (JEITA)
Total distortion ratio DVD: 0.1%, CD: 0.1%
Terminal
Antenna input DIN (input) terminal
Antenna output DIN (output) terminal
Video input SCART JACK (AV 1, 2) FRONT PIN JACK
Video output SCART JACK (AV 1, 2)
Audio input SCART JACK (AV 1, 2) FRONT PIN JACK
Audio output SCART JACK (AV 1, 2) PIN JACK (REAR)
S Video output MINI DIN 4PIN JACK (75 Ω)
Component Video output PIN JACK [DV-PF7E/PF7E(UK)]
Optical digital audio output Optical connector [DV-PF7E/PF7E(UK)]
Coaxial digital audio output PIN JACK
Others
Power supply AC 220-240 V +/-10%, 50 Hz +/-0.5%
Power consumption 30 W (Standby: 5.0 W)
Back-up time 30 s
Temperature range for
operation
5 °C - 40 °C
Dimensions 435(W) mm x 94(H) mm x 233(D) mm
Weight 3.2 kg
GENERAL INFORMATION 2
